Enerpac HCG15012 High Tonnage Load Return Single Acting Solid Plunger Hydraulic Cylinder, 168 ton Capacity, 6-1/2 in Bore, 11.81 in L Stroke, 19.57 in Retract, 3.7 in Dia Rod, 10150 psi Pressure

Enerpac

Enerpac HCG15012 High Tonnage Load Return Single Acting Solid Plunger Hydraulic Cylinder, 168 ton Capacity, 6-1/2 in Bore, 11.81 in L Stroke, 19.57 in Retract, 3.7 in Dia Rod, 10150 psi Pressure

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Enerpac

Enerpac HCG15012 High Tonnage Load Return Single Acting Solid Plunger Hydraulic Cylinder, 168 ton Capacity, 6-1/2 in Bore, 11.81 in L Stroke, 19.57 in Retract, 3.7 in Dia Rod, 10150 psi Pressure

ManufacturerEnerpac

Part #283591721

MFG #HCG15012

Enerpac Hydraulic Cylinder, High Tonnage Load Return Single Acting Solid Plunger, 168 ton, 6-1/2 in Bore, 11.81 in Stroke, 19.57 in Retract, Base Mount, 3/8-18 NPTF, 3.7 in Rod Dia, 10150 psi, Steel Housing, 8.46 in OD x 31.38 in H

$7,322.00

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Enerpac

Bore Size: 6-1/2 in

Capacity: 168 ton

Country of Origin: CN

Dimensions: 8.46 in OD x 31.38 in H

Housing Material: Steel

Manufacturer Name: Enerpac

Mounting Type: Base

Port Size: 3/8-18 NPTF

Pressure Rating: 10150 psi

Retract: 19.57 in

Rod Diameter: 3.7 in

Series: HCG

Stroke Length: 11.81 in

Type: High Tonnage Load Return Single Acting Solid Plunger

Hardened surface resists side loading and cyclic wear
10% side load resistance over full stroke
Stop ring to prevent plunger blow-out
Weather protected, inside and out
Upper and lower replaceable bearings enclose the cylinder plunger for support throughout the stroke
Certified lifting eyes, base mounting holes and collar threads

Instruction/Installation Manual

Specification Sheet

Warranty Information

Video Link

Manufacturer Name: Enerpac

Bore Size: 6-1/2 in

Capacity: 168 ton

Country of Origin: CN

Dimensions: 8.46 in OD x 31.38 in H

Housing Material: Steel

Manufacturer Name: Enerpac

Mounting Type: Base

Port Size: 3/8-18 NPTF

Pressure Rating: 10150 psi

Retract: 19.57 in

Rod Diameter: 3.7 in

Series: HCG

Stroke Length: 11.81 in

Type: High Tonnage Load Return Single Acting Solid Plunger

Hardened surface resists side loading and cyclic wear
10% side load resistance over full stroke
Stop ring to prevent plunger blow-out
Weather protected, inside and out
Upper and lower replaceable bearings enclose the cylinder plunger for support throughout the stroke
Certified lifting eyes, base mounting holes and collar threads

Instruction/Installation Manual

Specification Sheet

Warranty Information

Video Link
