Emuge BU109101.5042 Rekord 1A-H BU109101 Form C Reinforced Shank Straight Flute Machine Tap, Right Hand Cutting, #12-28 Thread, 2-3 Modified Bottoming Plug Chamfer, 3 Flutes, TiCN Coated, HSS-E

ManufacturerEmuge

Part #826513347

MFG #BU109101.5042

Emuge Straight Flute Machine Tap, Form C Reinforced Shank, Series: D4140-03-FM, Measurement System: Imperial, UNF, #12-28, 2-3 Modified Bottoming Plug Chamfer, 3 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.63 in Thread Length, 3.15 in Overall Length, 0.22 in Shank Dia, Cast Iron, Copper Alloys, Duroplastic, Graphite and Steel Material Application, No Through Coolant (Yes/No)

$45.22

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Emuge-Franken

Chamfer Type: 2-3 Modified Bottoming Plug

Class of Fit: 2BX

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: TiCN Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Material Application: Cast Iron, Copper Alloys, Duroplastic, Graphite and Steel

Measurement System: Imperial

Number of Flutes: 3

Overall Length: 3.15 in

Series: Rekord 1A-H BU109101

Shank Diameter: 0.22 in

Thread Length: 0.63 in

Thread Size: #12-28

Thread Standard: UNF

Through Coolant (Yes/No): No

Type: Form C Reinforced Shank

Taps with the A-H designation are specifically designed for high tensile, short chipping materials
The Rekord A flute geometry is designed for short chipping materials and produces chips that stay in the flutes
TiCN coating provides higher surface hardness and added lubricity for extended tool life
TiCN coated for wear-resistance and additional tool life
DIN/ANSI standard dimensions for overall length and shank size
Taps with DIN standard overall length dimensions are longer than taps made to ANSI standards
Replacement part for old tool series AU109101, now in expanded sizes

ASME B1.1|ANSI Specified|DIN 371, 376

Emuge Straight Flute Machine Tap, Form C Reinforced Shank, Series: D4140-03-FM, Measurement System: Imperial, UNF, #12-28, 2-3 Modified Bottoming Plug Chamfer, 3 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.63 in Thread Length, 3.15 in Overall Length, 0.22 in Shank Dia, Cast Iron, Copper Alloys, Duroplastic, Graphite and Steel Material Application, No Through Coolant (Yes/No)
