Emuge 2653AZ.010020 TiNox-Cut 2653AZ Extra Length Square End Corner Radius End Mill With Axial Through Coolant, 10 mm Dia Cutter, 2 mm Corner Radius, 22 mm Length of Cut, 4 Flutes, 10 mm Dia Shank, 80 mm OAL, TiAlN Coated

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

Emuge-Franken

Emuge 2653AZ.010020 TiNox-Cut 2653AZ Extra Length Square End Corner Radius End Mill With Axial Through Coolant, 10 mm Dia Cutter, 2 mm Corner Radius, 22 mm Length of Cut, 4 Flutes, 10 mm Dia Shank, 80 mm OAL, TiAlN Coated

ManufacturerEmuge

Part #826509447

MFG #2653AZ.010020

Emuge Corner Radius End Mill, Extra Length Square End, Series: TiNox-Cut 2653AZ, 10 mm Diameter Cutter, 2 mm Corner Radius, 80 mm Overall Length, 22 mm Length of Cut, 4 Flutes, Spiral Flute, 10 mm Shank Diameter, Right Hand Cutting Direction, 38/40 deg Helix Angle, Weldon Flat Shank, Carbide, TiAlN Coated

$164.98

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Emuge-Franken

Corner Radius: 2 mm

Country of Origin: DE

Cutter Diameter: 10 mm

Cutting Direction: Right Hand

Finish: TiAlN Coated

Flute Type: Spiral

Helix Angle: 38/40 deg

Length of Cut: 22 mm

Manufacturer Name: Emuge-Franken

Material: Carbide

Number of Flutes: 4

Overall Length: 80 mm

Series: TiNox-Cut 2653AZ

Shank Diameter: 10 mm

Shank Type: Weldon Flat

Type: Extra Length Square End

38/40 deg vibration dampening variable flute spacing
Fully blended corner radius
Heat and wear resistant TiAlN - PVD applied coating
Finishing flute profile for tough materials
Coolant fed (axial) design for efficient chip evacuation
Tool shanks are held to h5 tolerance and have a roughened surface (non-polished) for greater gripping force
Machining of difficult to cut materials

Emuge Corner Radius End Mill, Extra Length Square End, Series: TiNox-Cut 2653AZ, 10 mm Diameter Cutter, 2 mm Corner Radius, 80 mm Overall Length, 22 mm Length of Cut, 4 Flutes, Spiral Flute, 10 mm Shank Diameter, Right Hand Cutting Direction, 38/40 deg Helix Angle, Weldon Flat Shank, Carbide, TiAlN Coated

DIN 6535|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Manufacturer Name: Emuge-Franken

Corner Radius: 2 mm

Country of Origin: DE

Cutter Diameter: 10 mm

Cutting Direction: Right Hand

Finish: TiAlN Coated

Flute Type: Spiral

Helix Angle: 38/40 deg

Length of Cut: 22 mm

Manufacturer Name: Emuge-Franken

Material: Carbide

Number of Flutes: 4

Overall Length: 80 mm

Series: TiNox-Cut 2653AZ

Shank Diameter: 10 mm

Shank Type: Weldon Flat

Type: Extra Length Square End

38/40 deg vibration dampening variable flute spacing
Fully blended corner radius
Heat and wear resistant TiAlN - PVD applied coating
Finishing flute profile for tough materials
Coolant fed (axial) design for efficient chip evacuation
Tool shanks are held to h5 tolerance and have a roughened surface (non-polished) for greater gripping force
Machining of difficult to cut materials

Emuge Corner Radius End Mill, Extra Length Square End, Series: TiNox-Cut 2653AZ, 10 mm Diameter Cutter, 2 mm Corner Radius, 80 mm Overall Length, 22 mm Length of Cut, 4 Flutes, Spiral Flute, 10 mm Shank Diameter, Right Hand Cutting Direction, 38/40 deg Helix Angle, Weldon Flat Shank, Carbide, TiAlN Coated

DIN 6535|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer
