Emuge BU20S810.5613 Rekord B-AL BU20S810 Form B STI Tap, #6-32 Thread, 3 Flutes, 3B Class of Fit, Plug Chamfer, Right Hand Cutting, UNC Thread

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

Emuge-Franken

Emuge BU20S810.5613 Rekord B-AL BU20S810 Form B STI Tap, #6-32 Thread, 3 Flutes, 3B Class of Fit, Plug Chamfer, Right Hand Cutting, UNC Thread

ManufacturerEmuge

Part #826500684

MFG #BU20S810.5613

Emuge STI Tap, Form B, Series: Rekord B-AL BU20S810, Measurement System: Imperial, #6-32 Thread, UNC Thread Standard, 0.472 in Thread Length, 2.205 in Overall Length, 3 Flutes, Plug Chamfer, Right Hand Cutting Direction, Class of Fit: 3B, 0.141 in Shank Diameter, HSS-E, GLT-8 Coated

$61.03

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Emuge-Franken

Chamfer Type: Plug

Class of Fit: 3B

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: GLT-8 Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Measurement System: Imperial

Number of Flutes: 3

Overall Length: 2.205 in

Series: Rekord B-AL BU20S810

Shank Diameter: 0.141 in

Thread Length: 0.472 in

Thread Size: #6-32

Thread Standard: UNC

Type: Form B

Rekord B-AL tap is a plug style tap designed for wrought aluminum materials
Higher rake angle provides better shearing action for maximum tool life
Best suited for through hole applications
PVD applied GLT-8 non-stick/low friction coating is well suited for threading aluminum alloys
DIN/ANSI taps made with Emuge trademark long shanks - DIN length for extra reach and ANSI shanks

DIN/ANSI Standard|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Emuge STI Tap, Form B, Series: Rekord B-AL BU20S810, Measurement System: Imperial, #6-32 Thread, UNC Thread Standard, 0.472 in Thread Length, 2.205 in Overall Length, 3 Flutes, Plug Chamfer, Right Hand Cutting Direction, Class of Fit: 3B, 0.141 in Shank Diameter, HSS-E, GLT-8 Coated

Manufacturer Name: Emuge-Franken

Chamfer Type: Plug

Class of Fit: 3B

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: GLT-8 Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Measurement System: Imperial

Number of Flutes: 3

Overall Length: 2.205 in

Series: Rekord B-AL BU20S810

Shank Diameter: 0.141 in

Thread Length: 0.472 in

Thread Size: #6-32

Thread Standard: UNC

Type: Form B

Rekord B-AL tap is a plug style tap designed for wrought aluminum materials
Higher rake angle provides better shearing action for maximum tool life
Best suited for through hole applications
PVD applied GLT-8 non-stick/low friction coating is well suited for threading aluminum alloys
DIN/ANSI taps made with Emuge trademark long shanks - DIN length for extra reach and ANSI shanks

DIN/ANSI Standard|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Emuge STI Tap, Form B, Series: Rekord B-AL BU20S810, Measurement System: Imperial, #6-32 Thread, UNC Thread Standard, 0.472 in Thread Length, 2.205 in Overall Length, 3 Flutes, Plug Chamfer, Right Hand Cutting Direction, Class of Fit: 3B, 0.141 in Shank Diameter, HSS-E, GLT-8 Coated
