Emuge-Franken

Emuge AU109101.5048 Rekord A-H AU109101 Form C Reduced Shank Straight Flute Machine Tap, Right Hand Cutting, 9/16-18 Thread, Modified Bottoming Chamfer, 4 Flutes, TiCN Coated, HSS-E

ManufacturerEmuge

Part #826500044

MFG #AU109101.5048

Emuge Straight Flute Machine Tap, Form C Reduced Shank, Series: Rekord A-H AU109101, Measurement System: Imperial, UNF, 9/16-18, Modified Bottoming Chamfer, 4 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.866 in Thread Length, 3.59 in Overall Length, 0.429 in Shank Dia, 2.72 in Shank Length, Steel, Cast Iron, Copper Alloys and Synthetics Material Application, No Through Coolant (Yes/No)

$127.92

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Emuge-Franken

Chamfer Type: Modified Bottoming

Class of Fit: 2BX

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: TiCN Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Material Application: Steel, Cast Iron, Copper Alloys and Synthetics

Measurement System: Imperial

Number of Flutes: 4

Overall Length: 3.59 in

Series: Rekord A-H AU109101

Shank Diameter: 0.429 in

Shank Length: 2.72 in

Thread Length: 0.866 in

Thread Size: 9/16-18

Thread Standard: UNF

Through Coolant (Yes/No): No

Type: Form C Reduced Shank

Rekord A-H is a straight flute design best suited for short chipping, high tensile strength materials
TiCN coated for wear resistance and additional tool life
ANSI/ANSI standard dimensions for overall length and shank size
Taps with ANSI standard overall length dimensions are shorter than taps made to DIN standards

Emuge Straight Flute Machine Tap, Form C Reduced Shank, Series: Rekord A-H AU109101, Measurement System: Imperial, UNF, 9/16-18, Modified Bottoming Chamfer, 4 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.866 in Thread Length, 3.59 in Overall Length, 0.429 in Shank Dia, 2.72 in Shank Length, Steel, Cast Iron, Copper Alloys and Synthetics Material Application, No Through Coolant (Yes/No)

ANSI/ANSI Specified|ASME B1.1|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Manufacturer Name: Emuge-Franken

Chamfer Type: Modified Bottoming

Class of Fit: 2BX

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: TiCN Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Material Application: Steel, Cast Iron, Copper Alloys and Synthetics

Measurement System: Imperial

Number of Flutes: 4

Overall Length: 3.59 in

Series: Rekord A-H AU109101

Shank Diameter: 0.429 in

Shank Length: 2.72 in

Thread Length: 0.866 in

Thread Size: 9/16-18

Thread Standard: UNF

Through Coolant (Yes/No): No

Type: Form C Reduced Shank

Rekord A-H is a straight flute design best suited for short chipping, high tensile strength materials
TiCN coated for wear resistance and additional tool life
ANSI/ANSI standard dimensions for overall length and shank size
Taps with ANSI standard overall length dimensions are shorter than taps made to DIN standards

Emuge Straight Flute Machine Tap, Form C Reduced Shank, Series: Rekord A-H AU109101, Measurement System: Imperial, UNF, 9/16-18, Modified Bottoming Chamfer, 4 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.866 in Thread Length, 3.59 in Overall Length, 0.429 in Shank Dia, 2.72 in Shank Length, Steel, Cast Iron, Copper Alloys and Synthetics Material Application, No Through Coolant (Yes/No)

ANSI/ANSI Specified|ASME B1.1|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer
