Sandvik Coromant 6198250 T-Max P Turning Insert, ANSI Code: CNMG 431-PMC 4325, CNMG Insert, Material Grade: K, P, 431 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron and Steel, Carbide, Manufacturers Grade: 4325

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Sandvik Coromant

Sandvik Coromant 6198250 T-Max P Turning Insert, ANSI Code: CNMG 431-PMC 4325, CNMG Insert, Material Grade: K, P, 431 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron and Steel, Carbide, Manufacturers Grade: 4325

ManufacturerSandvik Coromant

Part #826298250

MFG #6198250

Sandvik Coromant Turning Insert, Series: T-Max P, CNMG Insert, 431 Insert, Rhombic, 0.118 in Maximum Depth of Cut, 1/2 in Inscribed Circle, 0.187 in Thickness, 12 Seat, Negative Rake, PMC Chipbreaker, 0.016 in Corner Radius, 0.2029 in Hole Dia, Manufacturers Grade: 4325, ANSI Code: CNMG 431-PMC 4325, ISO Code: CNMG 12 04 04-PMC 4325, 80 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3+TiN Coated, Material Grade: K, P, For Use On: Cast Iron and Steel

$18.33

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

: Manufacturer Name: Sandvik Coromant
ANSI Code: CNMG 431-PMC 4325
Chipbreaker: PMC
Corner Radius: 0.016 in
Country of Origin: SE
Cutting Direction: Neutral
Finish: CVD-TiCN+Al2O3+TiN Coated
For Use On: Cast Iron and Steel
Hole Diameter: 0.2029 in
Included Angle: 80 deg
Inscribed Circle: 1/2 in
Insert Size: 431
Insert Style: CNMG
ISO Code: CNMG 12 04 04-PMC 4325
Manufacturer Name: Sandvik Coromant
Manufacturers Grade: 4325
Material: Carbide
Material Grade: K, P
Maximum Depth of Cut: 0.118 in
Rake: Negative
Relief Angle: 0 deg
Seat Size: 12
Series: T-Max P
Shape: Rhombic
Thickness: 0.187 in
: Sandvik Coromant Turning Insert, Series: T-Max P, CNMG Insert, 431 Insert, Rhombic, 0.118 in Maximum Depth of Cut, 1/2 in Inscribed Circle, 0.187 in Thickness, 12 Seat, Negative Rake, PMC Chipbreaker, 0.016 in Corner Radius, 0.2029 in Hole Dia, Manufacturers Grade: 4325, ANSI Code: CNMG 431-PMC 4325, ISO Code: CNMG 12 04 04-PMC 4325, 80 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3+TiN Coated, Material Grade: K, P, For Use On: Cast Iron and Steel
