Pramet 6753939 Turning Insert, ANSI Code: DNMG 331-FM T9325, DNMG Insert, Material Grade: K, M, P, S, 331 Insert, Diamond Shape, 11 Seat, Negative Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Pramet 6753939 Turning Insert, ANSI Code: DNMG 331-FM T9325, DNMG Insert, Material Grade: K, M, P, S, 331 Insert, Diamond Shape, 11 Seat, Negative Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide

ManufacturerPramet

Part #816753939

MFG #6753939

UPC #3603602893055

Pramet Turning Insert, DNMG Insert, 331 Insert, Diamond, 0.118 in Maximum Depth of Cut, 3/8 in Inscribed Circle, 3/16 in Thickness, 0.457 in Length, 11 Seat, Negative Rake, FM Chipbreaker, 1/64 in Corner Radius, 0.15 in Hole Dia, Manufacturers Grade: T9325, ANSI Code: DNMG 331-FM T9325, ISO Code: DNMG 110404E-FM T9325, 55 deg Included Angle, 0 deg Relief Angle, Carbide, CVD Coated, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

$12.05

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: DNMG 331-FM T9325

Chipbreaker: FM

Corner Radius: 1/64 in

Country of Origin: CZ

Finish: CVD Coated

For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

Hole Diameter: 0.15 in

Included Angle: 55 deg

Inscribed Circle: 3/8 in

Insert Size: 331

Insert Style: DNMG

ISO Code: DNMG 110404E-FM T9325

Length: 0.457 in

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9325

Material: Carbide

Material Grade: K, M, P, S

Maximum Depth of Cut: 0.118 in

Rake: Negative

Relief Angle: 0 deg

Seat Size: 11

Shape: Diamond

Thickness: 3/16 in

T9325 grade functionally gradient substrate
Relatively low content of cobalt binder phase
Highly versatile material with very good operational reliability
Special surface finish for coating
Medium and higher cutting speed
Continuous and interrupted cut
Unfavorable cutting conditions, continuous and/or interrupted cuts
Cutting geometry suitable for grooving and axial turning

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Finishing, Semi-Roughing and Drilling

Catalog

Manufacturer Name: Dormer Pramet

ANSI Code: DNMG 331-FM T9325

Chipbreaker: FM

Corner Radius: 1/64 in

Country of Origin: CZ

Finish: CVD Coated

For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

Hole Diameter: 0.15 in

Included Angle: 55 deg

Inscribed Circle: 3/8 in

Insert Size: 331

Insert Style: DNMG

ISO Code: DNMG 110404E-FM T9325

Length: 0.457 in

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9325

Material: Carbide

Material Grade: K, M, P, S

Maximum Depth of Cut: 0.118 in

Rake: Negative

Relief Angle: 0 deg

Seat Size: 11

Shape: Diamond

Thickness: 3/16 in

T9325 grade functionally gradient substrate
Relatively low content of cobalt binder phase
Highly versatile material with very good operational reliability
Special surface finish for coating
Medium and higher cutting speed
Continuous and interrupted cut
Unfavorable cutting conditions, continuous and/or interrupted cuts
Cutting geometry suitable for grooving and axial turning

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Finishing, Semi-Roughing and Drilling

Catalog
