Precision Twist Drill 5995734 QC0860P General Purpose Extra Length Drill, 11/64 in Drill - Fraction, 0.1719 in Drill - Decimal Inch, 8 in OAL, HSS

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Precision Twist Drill 5995734 QC0860P General Purpose Extra Length Drill, 11/64 in Drill - Fraction, 0.1719 in Drill - Decimal Inch, 8 in OAL, HSS

ManufacturerPrecision Twist Drill

Part #816055611

MFG #5995734

UPC #086071556110

Precision Twist Drill Extra Length Drill, General Purpose, Series: QC0860P, 11/64 in Drill Size - Fraction, 0.1719 in Drill Size - Decimal Inch, 8 in Overall Length, 10XD Cutting Depth, 2 Flutes, Parabolic Flute, 6 in Flute Length, 11/64 in Shank, Straight Shank, 135 deg Point, Split Point, Right Hand Cutting, HSS Cutting Edge, HSS, Bright, Applicable Materials: Magnetic Soft Steel, Structural Steel/Case Carburizing Steel, Plain Carbon Steel, Alloy Steel/Hardened Steel, Tempered Steel, Lamellar Graphite, Nodular Graphite/Malleable Cast Iron, Free Machining Stainless Steel and Ferritic + Austenitic, ANSI Specifications Met, No Through Coolant (Yes/No)

$31.28

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

Applicable Materials: Magnetic Soft Steel, Structural Steel/Case Carburizing Steel, Plain Carbon Steel, Alloy Steel/Hardened Steel, Tempered Steel, Lamellar Graphite, Nodular Graphite/Malleable Cast Iron, Free Machining Stainless Steel and Ferritic + Austenitic

Country of Origin: FR

Cutting Depth: 10XD

Cutting Direction: Right Hand

Cutting Edge Material: HSS

Drill Size - Decimal Inch: 0.1719 in

Drill Size - Fraction: 11/64 in

Finish: Bright

Flute Length: 6 in

Flute Type: Parabolic

Manufacturer Name: Dormer Pramet

Material: HSS

Number of Flutes: 2

Overall Length: 8 in

Point Angle: 135 deg

Point Type: Split

Series: QC0860P

Shank Size: 11/64 in

Shank Type: Straight

Specifications Met: ANSI

Through Coolant (Yes/No): No

Type: General Purpose

Heavy duty parabolic flute design for efficient chip removal
Allows greater drilling depths in one pass
Low thrust design self-centering split point for easier penetration
Bright finish improves chip flow in soft or non-ferrous materials

ANSI Specified|CSA Approved

Specification Sheet

Catalog

Manufacturer Name: Dormer Pramet

Country of Origin: FR

Cutting Depth: 10XD

Cutting Direction: Right Hand

Cutting Edge Material: HSS

Drill Size - Decimal Inch: 0.1719 in

Drill Size - Fraction: 11/64 in

Finish: Bright

Flute Length: 6 in

Flute Type: Parabolic

Manufacturer Name: Dormer Pramet

Material: HSS

Number of Flutes: 2

Overall Length: 8 in

Point Angle: 135 deg

Point Type: Split

Series: QC0860P

Shank Size: 11/64 in

Shank Type: Straight

Specifications Met: ANSI

Through Coolant (Yes/No): No

Type: General Purpose

Heavy duty parabolic flute design for efficient chip removal
Allows greater drilling depths in one pass
Low thrust design self-centering split point for easier penetration
Bright finish improves chip flow in soft or non-ferrous materials

ANSI Specified|CSA Approved

Specification Sheet

Catalog
