Pramet 6754549 Positive Milling Insert, ANSI Code: ADMX -(2.5)2PR-R M9315, ADMX Insert, 11T308 Insert, Carbide, Manufacturers Grade: M9315, 85 deg Parallelogram Shape

ManufacturerPramet

Part #816054549

MFG #6754549

UPC #3603602899156

Pramet Milling Insert, Positive, ADMX Insert, 11T308 Insert, 85 deg Parallelogram, 6.53 mm Inscribed Circle, 3.97 mm Thickness, 11 mm Length, R Chipbreaker, 0.8 mm Corner Radius, 15 deg Lead Angle, 2.9 mm Hole Dia, Manufacturers Grade: M9315, ANSI Code: ADMX -(2.5)2PR-R M9315, ISO Code: ADMX 11T308PR-R M9315, Right Hand, Carbide, CVD Coated, Steel, Cast Iron and Hardened Steel Material Application

$16.25

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: ADMX -(2.5)2PR-R M9315

Chipbreaker: R

Corner Radius: 0.8 mm

Country of Origin: CZ

Finish: CVD Coated

Hand of Insert: Right

Hole Diameter: 2.9 mm

Inscribed Circle: 6.53 mm

Insert Size: 11T308

Insert Style: ADMX

ISO Code: ADMX 11T308PR-R M9315

Lead Angle: 15 deg

Length: 11 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: M9315

Material: Carbide

Material Application: Steel, Cast Iron and Hardened Steel

Shape: 85 deg Parallelogram

Thickness: 3.97 mm

Type: Positive

Fine grained substrate with a lower content of bonding cobalt phase
Thin MT-CVD coating with a unique Al2O3 layer
Suited to medium to high cutting speeds
High abrasion resistance while retaining a good level of strength

For dry machining and general machining
