Pramet 6754543 Positive Milling Insert, ANSI Code: ADMX -42PR-R M9325, ADMX Insert, 160608 Insert, Carbide, Manufacturers Grade: M9325, 85 deg Parallelogram Shape

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Pramet 6754543 Positive Milling Insert, ANSI Code: ADMX -42PR-R M9325, ADMX Insert, 160608 Insert, Carbide, Manufacturers Grade: M9325, 85 deg Parallelogram Shape

ManufacturerPramet

Part #816054543

MFG #6754543

UPC #3603602899095

Pramet Milling Insert, Positive, ADMX Insert, 160608 Insert, 85 deg Parallelogram, 9.95 mm Inscribed Circle, 6.25 mm Thickness, 16 mm Length, R Chipbreaker, 0.8 mm Corner Radius, 15 deg Lead Angle, 4.5 mm Hole Dia, Manufacturers Grade: M9325, ANSI Code: ADMX -42PR-R M9325, ISO Code: ADMX 160608PR-R M9325, Right Hand, Carbide, CVD Coated, Steel, Stainless Steel and Titanium/Super Alloy Material Application

$18.55

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: ADMX -42PR-R M9325

Chipbreaker: R

Corner Radius: 0.8 mm

Country of Origin: CZ

Finish: CVD Coated

Hand of Insert: Right

Hole Diameter: 4.5 mm

Inscribed Circle: 9.95 mm

Insert Size: 160608

Insert Style: ADMX

ISO Code: ADMX 160608PR-R M9325

Lead Angle: 15 deg

Length: 16 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: M9325

Material: Carbide

Material Application: Steel, Stainless Steel and Titanium/Super Alloy

Shape: 85 deg Parallelogram

Thickness: 6.25 mm

Type: Positive

Fine grained substrate with a high content of bonding cobalt phase
Thin MT-CVD coating with a unique Al2O3 layer
Suited to medium to high cutting speeds
High strength and operational reliability
Good wear resistance

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

General Machining Applications
