Pramet 6754160 Turning Insert Pramet, ANSI Code: SPMR 322-46:T9325, SPMR Insert, Material Grade: K, M, P, S, 322 Insert, Squared Shape, 9 Seat, Positive Rake, For Use On Stainless Steel, Steel, Cast Iron and Titanium/Super Alloys, Carbide

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Pramet 6754160 Turning Insert Pramet, ANSI Code: SPMR 322-46:T9325, SPMR Insert, Material Grade: K, M, P, S, 322 Insert, Squared Shape, 9 Seat, Positive Rake, For Use On Stainless Steel, Steel, Cast Iron and Titanium/Super Alloys, Carbide

ManufacturerPramet

Part #816054160

MFG #6754160

UPC #3603602895264

Pramet Turning Insert Pramet, SPMR Insert, 322 Insert, Squared, 3 mm Maximum Depth of Cut, 9.525 mm Inscribed Circle, 3.18 mm Thickness, 9.525 mm Width, 9.525 mm Length, 9 Seat, Positive Rake, 46 Chipbreaker, 0.8 mm Corner Radius, Manufacturers Grade: T9325, ANSI Code: SPMR 322-46:T9325, ISO Code: SPMR 090308E-46:T9325, 90 deg Included Angle, 11 deg Relief Angle, Carbide, CVD Coated, Material Grade: K, M, P, S, For Use On: Stainless Steel, Steel, Cast Iron and Titanium/Super Alloys

$6.30

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: SPMR 322-46:T9325

Chipbreaker: 46

Corner Radius: 0.8 mm

Country of Origin: CZ

Finish: CVD Coated

For Use On: Stainless Steel, Steel, Cast Iron and Titanium/Super Alloys

Included Angle: 90 deg

Inscribed Circle: 9.525 mm

Insert Size: 322

Insert Style: SPMR

ISO Code: SPMR 090308E-46:T9325

Length: 9.525 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9325

Material: Carbide

Material Grade: K, M, P, S

Maximum Depth of Cut: 3 mm

Rake: Positive

Relief Angle: 11 deg

Seat Size: 9

Shape: Squared

Thickness: 3.18 mm

Width: 9.525 mm

T9325 grade functionally gradient substrate
Relatively low content of cobalt binder phase
Thick MT-CVD coating
Highly versatile material with very good operational reliability
Special surface finish for coating
Medium and higher cutting speed
Continuous and interrupted cut
Unfavorable cutting conditions, continuous and/or interrupted cuts
Cutting geometry suitable for grooving and axial turning
For fine turning and finishing
