Pramet 6754045 Turning Insert Pramet, ANSI Code: SNMG 434-RM:T9315, SNMG Insert, Material Grade: H, K, P, 434 Insert, Squared Shape, 12 Seat, Negative Rake, For Use On Steel, Cast Iron and Hardened Steel, Carbide, Manufacturers Grade: T9315

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Pramet 6754045 Turning Insert Pramet, ANSI Code: SNMG 434-RM:T9315, SNMG Insert, Material Grade: H, K, P, 434 Insert, Squared Shape, 12 Seat, Negative Rake, For Use On Steel, Cast Iron and Hardened Steel, Carbide, Manufacturers Grade: T9315

ManufacturerPramet

Part #816054045

MFG #6754045

UPC #3603602894113

Pramet Turning Insert Pramet, SNMG Insert, 434 Insert, Squared, 0.276 in Maximum Depth of Cut, 1/2 in Inscribed Circle, 3/16 in Thickness, 1/2 in Width, 1/2 in Length, 12 Seat, Negative Rake, RM Chipbreaker, 1/16 in Corner Radius, 0.203 in Hole Dia, Manufacturers Grade: T9315, ANSI Code: SNMG 434-RM:T9315, ISO Code: SNMG 120416E-RM:T9315, 90 deg Included Angle, 0 deg Relief Angle, Carbide, CVD Coated, Material Grade: H, K, P, For Use On: Steel, Cast Iron and Hardened Steel

$9.68

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: SNMG 434-RM:T9315

Chipbreaker: RM

Corner Radius: 1/16 in

Country of Origin: CZ

Finish: CVD Coated

For Use On: Steel, Cast Iron and Hardened Steel

Hole Diameter: 0.203 in

Included Angle: 90 deg

Inscribed Circle: 1/2 in

Insert Size: 434

Insert Style: SNMG

ISO Code: SNMG 120416E-RM:T9315

Length: 1/2 in

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9315

Material: Carbide

Material Grade: H, K, P

Maximum Depth of Cut: 0.276 in

Rake: Negative

Relief Angle: 0 deg

Seat Size: 12

Shape: Squared

Thickness: 3/16 in

Width: 1/2 in

T9315 grade functionally gradient substrate with fine structure
Relatively low cobalt content
Thick MT-CVD coating with a dominant Al2O3 layer
Highly versatile material with a balanced ratio of abrasion resistance and operative reliability
Special surface finish for coating
High cutting speeds
Continuous to slightly interrupted cut

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Specification Sheet

Catalog

Manufacturer Name: Dormer Pramet

ANSI Code: SNMG 434-RM:T9315

Chipbreaker: RM

Corner Radius: 1/16 in

Country of Origin: CZ

Finish: CVD Coated

For Use On: Steel, Cast Iron and Hardened Steel

Hole Diameter: 0.203 in

Included Angle: 90 deg

Inscribed Circle: 1/2 in

Insert Size: 434

Insert Style: SNMG

ISO Code: SNMG 120416E-RM:T9315

Length: 1/2 in

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9315

Material: Carbide

Material Grade: H, K, P

Maximum Depth of Cut: 0.276 in

Rake: Negative

Relief Angle: 0 deg

Seat Size: 12

Shape: Squared

Thickness: 3/16 in

Width: 1/2 in

T9315 grade functionally gradient substrate with fine structure
Relatively low cobalt content
Thick MT-CVD coating with a dominant Al2O3 layer
Highly versatile material with a balanced ratio of abrasion resistance and operative reliability
Special surface finish for coating
High cutting speeds
Continuous to slightly interrupted cut

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Specification Sheet

Catalog
