Pramet 6751859 Turning Insert Pramet, ANSI Code: WCGT 32.52F-AL HF7, WCGT Insert, Material Grade: H, K, M, N, S, 32.52 Insert, Trigon Shape, 6 Seat, Positive Rake, For Use On Hardened Steel, Cast Iron, Stainless Steel, Aluminum and Titanium/Super Alloys

ManufacturerPramet

Part #816051859

MFG #6751859

UPC #3603602872258

Pramet Turning Insert Pramet, WCGT Insert, 32.52 Insert, Trigon, 0.165 in Maximum Depth of Cut, 3/8 in Inscribed Circle, 5/32 in Thickness, 6 Seat, Positive Rake, AL Chipbreaker, 1/32 in Corner Radius, 0.173 in Hole Dia, Manufacturers Grade: HF7, ANSI Code: WCGT 32.52F-AL HF7, ISO Code: WCGT 06T308F-AL HF7, 80 deg Included Angle, 7 deg Relief Angle, Carbide, PCD Coated, Material Grade: H, K, M, N, S, For Use On: Hardened Steel, Cast Iron, Stainless Steel, Aluminum and Titanium/Super Alloys

$11.15

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: WCGT 32.52F-AL HF7

Chipbreaker: AL

Corner Radius: 1/32 in

Country of Origin: CZ

Finish: PCD Coated

For Use On: Hardened Steel, Cast Iron, Stainless Steel, Aluminum and Titanium/Super Alloys

Hole Diameter: 0.173 in

Included Angle: 80 deg

Inscribed Circle: 3/8 in

Insert Size: 32.52

Insert Style: WCGT

ISO Code: WCGT 06T308F-AL HF7

Manufacturer Name: Dormer Pramet

Manufacturers Grade: HF7

Material: Carbide

Material Grade: H, K, M, N, S

Maximum Depth of Cut: 0.165 in

Rake: Positive

Relief Angle: 7 deg

Seat Size: 6

Shape: Trigon

Thickness: 5/32 in

HF7 grade sub-micron material without cubic carbides (type H) and with a low cobalt content
Very versatile in terms of machined materials
Small to medium chip cross sections
Suited to stable machining conditions
Suitable for turning, with an indexing accuracy to ISO tolerance class-G and chipbreakers on one side only
