Pramet 7038140 Turning Insert, ANSI Code: WNMG 433-NMR T9325, WNMG Insert, Material Grade: K, M, P, S, 433 Insert, Trigon Shape, 8 Seat, Negative Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide

ManufacturerPramet

Part #816038140

MFG #7038140

UPC #3603603112179

Pramet Turning Insert, WNMG Insert, 433 Insert, Trigon, 5 mm Maximum Depth of Cut, 1/2 in Inscribed Circle, 4.76 mm Thickness, 8 Seat, Negative Rake, NMR Chipbreaker, 1.2 mm Corner Radius, 5.16 mm Hole Dia, Manufacturers Grade: T9325, ANSI Code: WNMG 433-NMR T9325, ISO Code: WNMG 080412E-NMR T9325, 80 deg Included Angle, 0 deg Relief Angle, Carbide, CVD Coated, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

$10.65

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: WNMG 433-NMR T9325

Chipbreaker: NMR

Corner Radius: 1.2 mm

Country of Origin: CZ

Finish: CVD Coated

For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

Hole Diameter: 5.16 mm

Included Angle: 80 deg

Inscribed Circle: 1/2 in

Insert Size: 433

Insert Style: WNMG

ISO Code: WNMG 080412E-NMR T9325

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9325

Material: Carbide

Material Grade: K, M, P, S

Maximum Depth of Cut: 5 mm

Rake: Negative

Relief Angle: 0 deg

Seat Size: 8

Shape: Trigon

Thickness: 4.76 mm

T9325 grade functionally gradient substrate
Relatively low content of cobalt binder phase
Thick MT-CVD coating
Highly versatile material with very good operational reliability
Special surface finish for coating
Medium and higher cutting speed
Continuous and interrupted cut
Unfavorable cutting conditions, continuous and/or interrupted cuts
Cutting geometry suitable for grooving and axial turning
For fine turning and finishing
Suitable for turning, with an indexing accuracy to ISO tolerance class-M and chipbreakers on both sides
NMR chipbreaker - comprehensive offer of double-sided chipbreakers for turning stainless steels
High productivity, due to higher metal removal rates
Predictable insert behavior
Increased reliability thanks to advanced cutting edge strength with protective peripheral land
Ideal for heavy and less stable conditions
Positive geometry with a protective land
Medium to roughing operations
Suitable for longitudinal and face turning with high stock removal

Pramet Turning Insert, WNMG Insert, 433 Insert, Trigon, 5 mm Maximum Depth of Cut, 1/2 in Inscribed Circle, 4.76 mm Thickness, 8 Seat, Negative Rake, NMR Chipbreaker, 1.2 mm Corner Radius, 5.16 mm Hole Dia, Manufacturers Grade: T9325, ANSI Code: WNMG 433-NMR T9325, ISO Code: WNMG 080412E-NMR T9325, 80 deg Included Angle, 0 deg Relief Angle, Carbide, CVD Coated, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys
