Pramet 6922738 Turning Insert Pramet, ANSI Code: TNMG 332L-SI T8315, TNMG Insert, Material Grade: H, K, M, N, P, S, 332 Insert, Triangular Shape, 16 Seat, Negative Rake, Left Hand Cutting, Carbide, Manufacturers Grade: T8315

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Pramet 6922738 Turning Insert Pramet, ANSI Code: TNMG 332L-SI T8315, TNMG Insert, Material Grade: H, K, M, N, P, S, 332 Insert, Triangular Shape, 16 Seat, Negative Rake, Left Hand Cutting, Carbide, Manufacturers Grade: T8315

ManufacturerPramet

Part #816022738

MFG #6922738

UPC #3603603075641

Pramet Turning Insert Pramet, TNMG Insert, 332 Insert, Triangular, 5 mm Maximum Depth of Cut, 9.525 mm Inscribed Circle, 3/16 in Thickness, 16.5 mm Length, 16 Seat, Negative Rake, SI Chipbreaker, 0.8 mm Corner Radius, 3.81 mm Hole Dia, Manufacturers Grade: T8315, ANSI Code: TNMG 332L-SI T8315, ISO Code: TNMG 160408EL-SI T8315, 60 deg Included Angle, 0 deg Relief Angle, Left Hand Cutting, Carbide, CVD Coated, Material Grade: H, K, M, N, P, S, For Use On: Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloys

$8.45

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: TNMG 332L-SI T8315

Chipbreaker: SI

Corner Radius: 0.8 mm

Country of Origin: CZ

Cutting Direction: Left Hand

Finish: CVD Coated

For Use On: Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloys

Hole Diameter: 3.81 mm

Included Angle: 60 deg

Inscribed Circle: 9.525 mm

Insert Size: 332

Insert Style: TNMG

ISO Code: TNMG 160408EL-SI T8315

Length: 16.5 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T8315

Material: Carbide

Material Grade: H, K, M, N, P, S

Maximum Depth of Cut: 5 mm

Rake: Negative

Relief Angle: 0 deg

Seat Size: 16

Shape: Triangular

Thickness: 3/16 in

T8315 grade highly abrasion resistant material of the T8300 series with guaranteed strength
Sub-micron substrate with a relatively low cobalt content
Nano-layered PVD coating with gradient transitions
Lower internal coating tension with higher hardness
Lower notch wear on the main cutting edge
High cutting speeds
Medium chip cross sections
Stable machining conditions
Rounded edge

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Catalog

Specification Sheet

Manufacturer Name: Dormer Pramet

ANSI Code: TNMG 332L-SI T8315

Chipbreaker: SI

Corner Radius: 0.8 mm

Country of Origin: CZ

Cutting Direction: Left Hand

Finish: CVD Coated

For Use On: Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloys

Hole Diameter: 3.81 mm

Included Angle: 60 deg

Inscribed Circle: 9.525 mm

Insert Size: 332

Insert Style: TNMG

ISO Code: TNMG 160408EL-SI T8315

Length: 16.5 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T8315

Material: Carbide

Material Grade: H, K, M, N, P, S

Maximum Depth of Cut: 5 mm

Rake: Negative

Relief Angle: 0 deg

Seat Size: 16

Shape: Triangular

Thickness: 3/16 in

T8315 grade highly abrasion resistant material of the T8300 series with guaranteed strength
Sub-micron substrate with a relatively low cobalt content
Nano-layered PVD coating with gradient transitions
Lower internal coating tension with higher hardness
Lower notch wear on the main cutting edge
High cutting speeds
Medium chip cross sections
Stable machining conditions
Rounded edge

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Catalog

Specification Sheet
