Pramet 6800852 Positive Milling Insert, SDMT Insert, 120508 Insert, Carbide, Manufacturers Grade: M8340, Squared Shape

ManufacturerPramet

Part #816000852

MFG #6800852

UPC #3603602993830

Pramet Milling Insert, Positive, SDMT Insert, 120508 Insert, Squared, 12.7 mm Inscribed Circle, 5 mm Thickness, 12.7 mm Width, 12.7 mm Length, M Chipbreaker, 0.8 mm Corner Radius, 15 deg Lead Angle, 4.4 mm Hole Dia, Manufacturers Grade: M8340, ISO Code: SDMT 120508SR-M M8340, Right Hand, Carbide, CVD Coated, Cast Iron, Stainless Steel, Steel, Super Alloys and Titanium Material Application

$16.25

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

Chipbreaker: M

Corner Radius: 0.8 mm

Country of Origin: CZ

Finish: CVD Coated

Hand of Insert: Right

Hole Diameter: 4.4 mm

Inscribed Circle: 12.7 mm

Insert Size: 120508

Insert Style: SDMT

ISO Code: SDMT 120508SR-M M8340

Lead Angle: 15 deg

Length: 12.7 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: M8340

Material: Carbide

Material Application: Cast Iron, Stainless Steel, Steel, Super Alloys and Titanium

Shape: Squared

Thickness: 5 mm

Type: Positive

Width: 12.7 mm

Wear resistant type H submicron substrate
New PVD coating based on AlTiN layers
Multilayer coating system for enhanced toughness
Reduces the occurrence and spreading of comb micro cracks
Suitable for operations with a high thermal load
Larger chip cross-sections, wide range of cutting speeds
Unstable working conditions

General Machining Applications

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov
