Seco Niagara Cutter 17003473 Elite S545 Center Cutting High Performance Medium Length Single End Square End End Mill, 1 in Dia Cutter, 2-5/8 in Length of Cut, 5 Flutes, 1 in Dia Shank, 6 in OAL, Uncoated

ManufacturerSeco

Part #803661875

MFG #N61875

Seco Niagara Cutter End Mill, Center Cutting High Performance Medium Length Single End Square End, Series: Elite S545, 1 in Diameter Cutter, 6 in Overall Length, 2-5/8 in Length of Cut, 5 Flutes, Spiral Flute, 1 in Shank Diameter, Right Hand Cutting Direction, 45 deg Helix Angle, Cylindrical Shank, ANSI Code: S545-1.000-D3-S.0-Z5, ISO Code: S5451.00D3S.0Z5, Solid Carbide, Uncoated

$418.33

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Seco Tools

ANSI Code: S545-1.000-D3-S.0-Z5

Country of Origin: US

Cutter Diameter: 1 in

Cutting Direction: Right Hand

Finish: Uncoated

Flute Type: Spiral

Helix Angle: 45 deg

ISO Code: S5451.00D3S.0Z5

Length of Cut: 2-5/8 in

Manufacturer Name: Seco Tools

Material: Solid Carbide

Number of Flutes: 5

Overall Length: 6 in

Series: Elite S545

Shank Diameter: 1 in

Shank Type: Cylindrical

Type: Center Cutting High Performance Medium Length Single End Square End

Solid carbide provides better rigidity than high speed steel, it is extremely heat resistant and used for high speed applications on cast iron, non-ferrous materials, plastics and other tough-to-machine materials
Uncoated tools do not feature supportive treatments on the cutting edge, they are used at reduced speeds for general applications on non-ferrous metals
90 deg cutting edge
2.281 in L minimum clamping
45 deg axial rake
10 deg radial rake
Ideal for peripheral finish milling in steel, stainless steel, titanium and high temperature alloys
D - Cylindrical tool shape
Square nose end mills (also called square end) create sharp, unrounded cuts

Seco Niagara Cutter End Mill, Center Cutting High Performance Medium Length Single End Square End, Series: Elite S545, 1 in Diameter Cutter, 6 in Overall Length, 2-5/8 in Length of Cut, 5 Flutes, Spiral Flute, 1 in Shank Diameter, Right Hand Cutting Direction, 45 deg Helix Angle, Cylindrical Shank, ANSI Code: S545-1.000-D3-S.0-Z5, ISO Code: S5451.00D3S.0Z5, Solid Carbide, Uncoated
