Seco 02565024 335.19 Disc Milling Cutter, ANSI Code: R335.19-3263.0-04.4, Shank Connection, 63 mm Dia x 4 mm W Cutting, SNHQ Insert, 13.9 mm Max Depth of Cut

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

Seco Tools

Seco 02565024 335.19 Disc Milling Cutter, ANSI Code: R335.19-3263.0-04.4, Shank Connection, 63 mm Dia x 4 mm W Cutting, SNHQ Insert, 13.9 mm Max Depth of Cut

ManufacturerSeco

Part #288531020

MFG #02565024

Seco Disc Milling Cutter, Series: 335.19, 63 mm Cutting Dia, 170 mm Overall Length, 4 mm Cutting Width, SNHQ Insert, 8 Inserts, Insert Compatibility: 1102..R, 1102..L, 4 mm Head Length, 32 mm Shank Dia, Shank Shank, 148.6 mm Shank Length, Shank, 13.9 mm Maximum Depth of Cut, ANSI Code: R335.19-3263.0-04.4

$1,240.00

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Seco Tools

ANSI Code: R335.19-3263.0-04.4

Connection Type: Cylindrical, Shank

Country of Origin: FR

Cutting Diameter: 63 mm

Cutting Width: 4 mm

Head Length: 4 mm

Insert Compatibility: 1102..R, 1102..L

Insert Style: SNHQ

Manufacturer Name: Seco Tools

Maximum Depth of Cut: 13.9 mm

Number of Inserts: 8

Overall Length: 170 mm

Series: 335.19

Shank Diameter: 32 mm

Shank Length: 148.6 mm

Shank Type: Cylindrical

Economical, precise and free cutting solution for small width of cut

Our extensive range of standard disc milling cutters, insert radii, geometry and grades tackles any challenges brought by disc milling applications. With the widest range of inserts, cutter bodies, and attachment types in the industry, we are your single source tooling supplier for sawing, T-slotting, slotting, deep slotting, dual radius slotting, back facing, circular or helical interpolation, square shoulder milling, circlip grooving and copy milling. And our products are developed with extensive research to ensure they meet the needs to todays materials and machining processes. While our full line of standard disc milling cutters covers most applications, we also offer special design and manufacturing solutions for industry specific needs. This includes cutters for gear machining in the power generation industry, automotive crankshaft milling, large diameters cutter solutions for many typical aerospace components, cutters for oil and gas pipe sawing and cutters with round inserts for hip prosthesis.
