Seco Secomax 02944279 Turning Insert, ANSI Code: CNMN433S-00820P CBN600, CNMN Insert, 120412 Insert, Diamond Shape, 12 Seat, PCBN, Manufacturers Grade: CBN600

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Seco Tools

Seco Secomax 02944279 Turning Insert, ANSI Code: CNMN433S-00820P CBN600, CNMN Insert, 120412 Insert, Diamond Shape, 12 Seat, PCBN, Manufacturers Grade: CBN600

ManufacturerSeco

Part #288512465

MFG #02944279

Seco Secomax Turning Insert, CNMN Insert, 120412 Insert, Diamond, 5.25 mm Maximum Depth of Cut, 12.7 mm Inscribed Circle, 4.76 mm Thickness, 12 Seat, 1.2 mm Corner Radius, Manufacturers Grade: CBN600, ANSI Code: CNMN433S-00820P CBN600, ISO Code: CNMN120412S-02020P CBN600, 80 deg Included Angle, 0 deg Relief Angle, PCBN, Uncoated

$252.00

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

: Manufacturer Name: Seco Tools
ANSI Code: CNMN433S-00820P CBN600
Corner Radius: 1.2 mm
Country of Origin: SE
Finish: Uncoated
Included Angle: 80 deg
Inscribed Circle: 12.7 mm
Insert Size: 120412
Insert Style: CNMN
ISO Code: CNMN120412S-02020P CBN600
Manufacturer Name: Seco Tools
Manufacturers Grade: CBN600
Material: PCBN
Maximum Depth of Cut: 5.25 mm
Relief Angle: 0 deg
Seat Size: 12
Shape: Diamond
Thickness: 4.76 mm
: Polycrystalline cubic boron nitride (PCBN) is a material which is sintered at extremely high pressure and high temperature into a wear-resistant material with properties close to those of diamond. Due to the hot hardness, oxidation resistance and fracture toughness of the material, inserts made of PCBN have excellent edge strength and long tool life when machining hard ferrous materials and pearlitic grey cast iron.

: Manufacturer Name: Seco Tools
ANSI Code: CNMN433S-00820P CBN600
Corner Radius: 1.2 mm
Country of Origin: SE
Finish: Uncoated
Included Angle: 80 deg
Inscribed Circle: 12.7 mm
Insert Size: 120412
Insert Style: CNMN
ISO Code: CNMN120412S-02020P CBN600
Manufacturer Name: Seco Tools
Manufacturers Grade: CBN600
Material: PCBN
Maximum Depth of Cut: 5.25 mm
Relief Angle: 0 deg
Seat Size: 12
Shape: Diamond
Thickness: 4.76 mm
: Polycrystalline cubic boron nitride (PCBN) is a material which is sintered at extremely high pressure and high temperature into a wear-resistant material with properties close to those of diamond. Due to the hot hardness, oxidation resistance and fracture toughness of the material, inserts made of PCBN have excellent edge strength and long tool life when machining hard ferrous materials and pearlitic grey cast iron.
