Enerpac RC-256 General Purpose Industry Standard Single Acting Hydraulic Cylinder, 25 ton Capacity, 6-1/4 in L Stroke, 10000 psi
Pricing Notice
Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.
Terms of SaleHave a Question About a Product?
Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.
Contact UsEnerpac RC-256 General Purpose Industry Standard Single Acting Hydraulic Cylinder, 25 ton Capacity, 6-1/4 in L Stroke, 10000 psi
ManufacturerEnerpac
Part #283530138
MFG #RC256
UPC #662005301386
Enerpac Hydraulic Cylinder, General Purpose Industry Standard Single Acting, Series: RC, 25 ton, 6-1/4 in Stroke, 10000 psi, Steel Housing, Baked Enamel
$1,263.00
 / EAKnowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.
- Manufacturer Name:Â EnerpacCapacity:Â 25 tonCountry of Origin:Â CNFinish:Â Baked EnamelHousing Material:Â SteelManufacturer Name:Â EnerpacPressure Rating:Â 10000 psiSeries:Â RCStroke Length:Â 6-1/4 inType:Â General Purpose Industry Standard Single Acting
- RC series single acting hydraulic cylinders set the industry standard for general purpose cylinders
- Unique GR2 bearing design, reduces wear and extending life
- Collar threads, plunger threads and base mounting holes enable easy fixturing (on most models)
- Designed for use in all positions
- High strength alloy steel for durability
- Redesigned cylinder thread protector for ease of use
- Heavy duty, pretension spring improves retraction speed
- Baked enamel finish for increased corrosion resistance
- Plunger wiper reduces contamination, extending cylinder life
- All RC cylinders are equipped with hardened removable grooved saddles
- The exclusive GR2 is a unique bearing design on RC series DUO cylinders which absorbs eccentric load stresses to protect your cylinder against abrasion, over-extending or plunger blow-outs and jamming or top-end mushrooming
- 2.56 in cylindrical bore diameter
- 1 in base to advance port
- 2 in saddle diameter
- 0.41 in saddle protruding from plunger
- 1-1/2-16 UN plunger internal thread
- 1 in plunger thread length
- 2.31 in bolt circle
- 1/2-13 UN thread
- 3/4 in thread depth
CR-400 Coupler and Dust Cap
- CR-400 Coupler and Dust Cap
- ASME B30.1
- For safe disposal of old gas cylinders with hydraulic punch set, safely releasing furnace bricks from a steel fixture, removing the wheel studs on a caterpillar 777 dump truck and repairing the foundation of tilting silo with steel piers
- Manufacturer Name:Â EnerpacCapacity:Â 25 tonCountry of Origin:Â CNFinish:Â Baked EnamelHousing Material:Â SteelManufacturer Name:Â EnerpacPressure Rating:Â 10000 psiSeries:Â RCStroke Length:Â 6-1/4 inType:Â General Purpose Industry Standard Single Acting
- RC series single acting hydraulic cylinders set the industry standard for general purpose cylinders
- Unique GR2 bearing design, reduces wear and extending life
- Collar threads, plunger threads and base mounting holes enable easy fixturing (on most models)
- Designed for use in all positions
- High strength alloy steel for durability
- Redesigned cylinder thread protector for ease of use
- Heavy duty, pretension spring improves retraction speed
- Baked enamel finish for increased corrosion resistance
- Plunger wiper reduces contamination, extending cylinder life
- All RC cylinders are equipped with hardened removable grooved saddles
- The exclusive GR2 is a unique bearing design on RC series DUO cylinders which absorbs eccentric load stresses to protect your cylinder against abrasion, over-extending or plunger blow-outs and jamming or top-end mushrooming
- 2.56 in cylindrical bore diameter
- 1 in base to advance port
- 2 in saddle diameter
- 0.41 in saddle protruding from plunger
- 1-1/2-16 UN plunger internal thread
- 1 in plunger thread length
- 2.31 in bolt circle
- 1/2-13 UN thread
- 3/4 in thread depth
CR-400 Coupler and Dust Cap
- CR-400 Coupler and Dust Cap
- ASME B30.1
- For safe disposal of old gas cylinders with hydraulic punch set, safely releasing furnace bricks from a steel fixture, removing the wheel studs on a caterpillar 777 dump truck and repairing the foundation of tilting silo with steel piers
