Enerpac PATG5102NB Turbo II PATG Air Powered Hydraulic Pump, Foot or Hand Actuator, 12 scfm Air Flow, 120 cu-in/min Oil Displacement Rating, 3/8-18 NPTF Fluid Port, 1/4-18 NPTF Air Inlet

ManufacturerEnerpac

Part #283518816

MFG #PATG5102NB

Enerpac Hydraulic Pump, Air Powered, Series: Turbo II PATG, Foot or Hand Actuator, 5000 psi, 12 scfm, 120 cu-in/min Oil Displacement, 3/8-18 NPTF Fluid Port, 1/4-18 NPTF Air Inlet, 70 cu-in Vertical Mount/122 cu-in Horizontal Mount cu-in Oil, 116 cu-in Reservoir, 50 to 125 psi Air, 75 dBA, 13.66 in Length, 8 in Width, 8.54 in Height

$1,224.00

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Enerpac

Actuator Type: Foot or Hand

Air Flow Rate: 12 scfm

Air Inlet: 1/4-18 NPTF

Air Pressure: 50 to 125 psi

Capacity: 5000 psi

Country of Origin: US

Fluid Port Size: 3/8-18 NPTF

Height: 8.54 in

Length: 13.66 in

Manufacturer Name: Enerpac

Oil Capacity: 70 cu-in Vertical Mount/122 cu-in Horizontal Mount cu-in

Oil Displacement Rating: 120 cu-in/min

Reservoir Capacity: 116 cu-in

Series: Turbo II PATG

Sound Level: 75 dBA

Type: Air Powered

Width: 8 in

On demand stall restart operation maintains system pressure, providing clamping security
External adjustable pressure relief valve (behind sight glass)
Internal pressure relief valve provides overload protection
45:1 hydraulic to air ratio
Reinforced heavy duty lightweight reservoir for applications in tough environments
Five valve mounting options provide flexibility in setup and operation
Fully serviceable air motor assembly
User supplied valves
122 cu-in usable oil capacity horizontal mount and 70 cu-in usable oil capacity vertical mount

Turbo II air hydraulic pumps generate the hydraulic pressure you need using the air pressure you have available. The air saver piston reduces air consumption and operating costs. They are ideal for providing the power and speed desired in simple clamping circuits. Turbo II air hydraulic pumps are best suited to medium and lower cycle applications. At only 75 dBA, the Turbo II series helps to keep noise level to a minimum.

Catalog

Instruction/Installation Manual

Warranty Information

Video Link

Manufacturer Name: Enerpac

Actuator Type: Foot or Hand

Air Flow Rate: 12 scfm

Air Inlet: 1/4-18 NPTF

Air Pressure: 50 to 125 psi

Capacity: 5000 psi

Country of Origin: US

Fluid Port Size: 3/8-18 NPTF

Height: 8.54 in

Length: 13.66 in

Manufacturer Name: Enerpac

Oil Capacity: 70 cu-in Vertical Mount/122 cu-in Horizontal Mount cu-in

Oil Displacement Rating: 120 cu-in/min

Reservoir Capacity: 116 cu-in

Series: Turbo II PATG

Sound Level: 75 dBA

Type: Air Powered

Width: 8 in

On demand stall restart operation maintains system pressure, providing clamping security
External adjustable pressure relief valve (behind sight glass)
Internal pressure relief valve provides overload protection
45:1 hydraulic to air ratio
Reinforced heavy duty lightweight reservoir for applications in tough environments
Five valve mounting options provide flexibility in setup and operation
Fully serviceable air motor assembly
User supplied valves
122 cu-in usable oil capacity horizontal mount and 70 cu-in usable oil capacity vertical mount
