Enerpac RR-1012 Double Acting Long Stroke Hydraulic Cylinder, 10 ton Capacity, 12 in L Stroke, 10000 psi
Pricing Notice
Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.
Terms of SaleHave a Question About a Product?
Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.
Contact UsEnerpac RR-1012 Double Acting Long Stroke Hydraulic Cylinder, 10 ton Capacity, 12 in L Stroke, 10000 psi
ManufacturerEnerpac
Part #283503311
MFG #RR1012
UPC #662005303311
$2,434.00
 / EA- Manufacturer Name: EnerpacCapacity: 10 tonCountry of Origin: USFinish: Baked EnamelHousing Material: SteelManufacturer Name: EnerpacPressure Rating: 10000 psiSeries: RRStroke Length: 12 inType: Double Acting Long Stroke
- Double acting cylinders are rugged enough for the toughest job site uses and precision designed for high cycle industrial use
- Collar threads, plunger threads and base mounting holes enable easy fixturing (on most models)
- Baked enamel finish for increased corrosion resistance
- Removable hardened saddles protect plunger during lifting and pressing
- Built-in safety valve prevents accidental over pressurization
- Plunger wiper reduces contamination, extending cylinder life
- 2.23 sq-in push/0.8 sq-in pull cylinder effective area
- 18 in collapsed height
- 30 in extended height
- 1.69 in cylindrical bore diameter
- 1.44 in base to advance port
- 2-1/4 in top to return port
- 1.38 in saddle diameter
- 0.24 in saddle protrusion from plunger
- 1-8 plunger internal thread
- 1 in plunger thread length
- 2-1/4 -14 in collar thread
- 1.06 in collar thread length
- 2.88 in outside diameter
CR-400 Coupler
- For high cycle industrial use
- CR-400 Coupler
- ASME B30.1
- Manufacturer Name:Â EnerpacCapacity:Â 10 tonCountry of Origin:Â USFinish:Â Baked EnamelHousing Material:Â SteelManufacturer Name:Â EnerpacPressure Rating:Â 10000 psiSeries:Â RRStroke Length:Â 12 inType:Â Double Acting Long Stroke
- Double acting cylinders are rugged enough for the toughest job site uses and precision designed for high cycle industrial use
- Collar threads, plunger threads and base mounting holes enable easy fixturing (on most models)
- Baked enamel finish for increased corrosion resistance
- Removable hardened saddles protect plunger during lifting and pressing
- Built-in safety valve prevents accidental over pressurization
- Plunger wiper reduces contamination, extending cylinder life
- 2.23 sq-in push/0.8 sq-in pull cylinder effective area
- 18 in collapsed height
- 30 in extended height
- 1.69 in cylindrical bore diameter
- 1.44 in base to advance port
- 2-1/4 in top to return port
- 1.38 in saddle diameter
- 0.24 in saddle protrusion from plunger
- 1-8 plunger internal thread
- 1 in plunger thread length
- 2-1/4 -14 in collar thread
- 1.06 in collar thread length
- 2.88 in outside diameter
CR-400 Coupler
- For high cycle industrial use
- CR-400 Coupler
- ASME B30.1
