Haimer 75.121.DL12 Short Cylindrical Extension With Safe-Lock, DL12 Shank Connection, 11.5 mm Dia Nose, 6 mm Projection

ManufacturerHaimer

Part #129501697

MFG #75.121.DL12

Haimer Cylindrical Extension, Short, 2.5 mm Hole Dia, 11.5 mm Nose Dia, 6 mm Projection, 65 mm Overall Length, 12 mm Overall Dia, DL12 Shank Connection

$250.00

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Haimer

Hole Diameter: 2.5 mm

Nose Diameter: 11.5 mm

Overall Diameter: 12 mm

Overall Length: 65 mm

Projection: 6 mm

Shank Connection Size: DL12

Type: Short

Superior rigidity of the interface allows for greater depths of cut up to 1.5xD in full slotting
The most robust modular system ever developed
FEA based design ensures that stress levels in the interface remain below critical values even at elevated loads
The double cone surfaces, combined with an additional third supporting pilot, delivers high stiffness and accuracy
H6 shank tolerance
With inner coolant bore
