SGS 40350 03B Ball Nose End Metric End Mill, 8 mm Dia Cutter, 20 mm Length of Cut, 2 Flutes, 8 mm Dia Shank, 63 mm OAL, Uncoated

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

KYOCERA SGS Precision tools, Inc.

SGS 40350 03B Ball Nose End Metric End Mill, 8 mm Dia Cutter, 20 mm Length of Cut, 2 Flutes, 8 mm Dia Shank, 63 mm OAL, Uncoated

ManufacturerSGS

Part #069940350

MFG #40350

UPC #691781403502

SGS End Mill, Ball Nose End Metric, Series: 03B, 8 mm Diameter Cutter, 63 mm Overall Length, 20 mm Length of Cut, 2 Flutes, Spiral Flute, 8 mm Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Straight Shank, 1.693 in Shank Length, Micrograin Solid Carbide, Uncoated Finish

$28.47

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

: Manufacturer Name: KYOCERA SGS Precision tools, Inc.
Country of Origin: US
Cutter Diameter: 8 mm
Cutting Direction: Right Hand
Finish: Uncoated
Flute Type: Spiral
Helix Angle: 30 deg
Length of Cut: 20 mm
Manufacturer Name: KYOCERA Precision Tools, KYOCERA SGS Precision tools, Inc.
Material: Micrograin Solid Carbide
Number of Flutes: 2
Overall Length: 63 mm
Series: 03B
Shank Diameter: 8 mm
Shank Length: 1.693 in
Shank Type: Straight
Type: Ball Nose End Metric
: SGS End Mill, Ball Nose End Metric, Series: 03B, 8 mm Diameter Cutter, 63 mm Overall Length, 20 mm Length of Cut, 2 Flutes, Spiral Flute, 8 mm Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Straight Shank, 1.693 in Shank Length, Micrograin Solid Carbide, Uncoated Finish
