Emuge CW169401.5048 Rekord 2A-SPEED/E IKZ CW169401 Form E Reduced Shank Straight Flute Machine Tap, Right Hand Cutting, 9/16-18 Thread, Bottoming Chamfer, 4 Flutes, TiCN Coated, HSS-E

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

Emuge-Franken

Emuge CW169401.5048 Rekord 2A-SPEED/E IKZ CW169401 Form E Reduced Shank Straight Flute Machine Tap, Right Hand Cutting, 9/16-18 Thread, Bottoming Chamfer, 4 Flutes, TiCN Coated, HSS-E

ManufacturerEmuge

Part #826505044

MFG #CW169401.5048

Emuge Straight Flute Machine Tap, Form E Reduced Shank, Series: Rekord 2A-SPEED/E IKZ CW169401, Measurement System: Imperial, UNF, 9/16-18, Bottoming Chamfer, 4 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.866 in Thread Length, 3.937 in Overall Length, 0.429 in Shank Dia, 3.07 in Shank Length, Cast Iron, Aluminum Alloys and Copper Alloys Material Application

$196.10

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Emuge-Franken

Chamfer Type: Bottoming

Class of Fit: 2BX

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: TiCN Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Material Application: Cast Iron, Aluminum Alloys and Copper Alloys

Measurement System: Imperial

Number of Flutes: 4

Overall Length: 3.937 in

Series: Rekord 2A-SPEED/E IKZ CW169401

Shank Diameter: 0.429 in

Shank Length: 3.07 in

Thread Length: 0.866 in

Thread Size: 9/16-18

Thread Standard: UNF

Through Coolant (Yes/No): Yes

Type: Form E Reduced Shank

Speed taps are specifically made for high speed tapping in CNC machines
Rekord A/E-SPEED is a straight flute design for high speed tapping in short chipping materials
IKZ - axial coolant hole design for optimum chip evacuation
TiCN coated for additional tool life
DIN/ANSI taps made with Emuge trademark long shanks - DIN length for extra reach and ANSI shanks

DIN/ANSI Standard|ASME B1.1|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Emuge Straight Flute Machine Tap, Form E Reduced Shank, Series: Rekord 2A-SPEED/E IKZ CW169401, Measurement System: Imperial, UNF, 9/16-18, Bottoming Chamfer, 4 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.866 in Thread Length, 3.937 in Overall Length, 0.429 in Shank Dia, 3.07 in Shank Length, Cast Iron, Aluminum Alloys and Copper Alloys Material Application

Manufacturer Name: Emuge-Franken

Chamfer Type: Bottoming

Class of Fit: 2BX

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: TiCN Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Material Application: Cast Iron, Aluminum Alloys and Copper Alloys

Measurement System: Imperial

Number of Flutes: 4

Overall Length: 3.937 in

Series: Rekord 2A-SPEED/E IKZ CW169401

Shank Diameter: 0.429 in

Shank Length: 3.07 in

Thread Length: 0.866 in

Thread Size: 9/16-18

Thread Standard: UNF

Through Coolant (Yes/No): Yes

Type: Form E Reduced Shank

Speed taps are specifically made for high speed tapping in CNC machines
Rekord A/E-SPEED is a straight flute design for high speed tapping in short chipping materials
IKZ - axial coolant hole design for optimum chip evacuation
TiCN coated for additional tool life
DIN/ANSI taps made with Emuge trademark long shanks - DIN length for extra reach and ANSI shanks

DIN/ANSI Standard|ASME B1.1|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Emuge Straight Flute Machine Tap, Form E Reduced Shank, Series: Rekord 2A-SPEED/E IKZ CW169401, Measurement System: Imperial, UNF, 9/16-18, Bottoming Chamfer, 4 Flutes, HSS-E, TiCN Coated, Class of Fit: 2BX, Right Hand Cutting, 0.866 in Thread Length, 3.937 in Overall Length, 0.429 in Shank Dia, 3.07 in Shank Length, Cast Iron, Aluminum Alloys and Copper Alloys Material Application
