Sandvik Coromant 6042792 T-Max P Turning Insert, ANSI Code: CNMG 434-KRR 3210, CNMG Insert, Material Grade: K, 434 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron, Carbide, Manufacturer's Grade: 3210
Manufacturer: Sandvik Coromant
MFG #: 6042792
Sandvik Coromant 6042792 T-Max P Turning Insert, ANSI Code: CNMG 434-KRR 3210, CNMG Insert, Material Grade: K, 434 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron, Carbide, Manufacturer's Grade: 3210
Sandvik Coromant 6042792 T-Max P Turning Insert, ANSI Code: CNMG 434-KRR 3210, CNMG Insert, Material Grade: K, 434 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron, Carbide, Manufacturer's Grade: 3210
Sandvik Coromant 6042792 T-Max P Turning Insert, ANSI Code: CNMG 434-KRR 3210, CNMG Insert, Material Grade: K, 434 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron, Carbide, Manufacturer's Grade: 3210
Sandvik Coromant 6042792 T-Max P Turning Insert, ANSI Code: CNMG 434-KRR 3210, CNMG Insert, Material Grade: K, 434 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron, Carbide, Manufacturer's Grade: 3210

Your Price

$13.69 / EA
Pack10/PK
Available for Purchase
Available for Purchase
Sandvik Coromant 6042792 T-Max P Turning Insert, ANSI Code: CNMG 434-KRR 3210, CNMG Insert, Material Grade: K, 434 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron, Carbide, Manufacturer's Grade: 3210
Manufacturer: Sandvik Coromant
MFG #: 6042792

Your Price

$13.69 / EA
Pack10/PK

Details

Part#826242792

Manufacturer:Sandvik Coromant

MFG #6042792

Sandvik Coromant Turning Insert, Series: T-Max P, CNMG Insert, 434 Insert, Rhombic, 0.315 in Maximum Depth of Cut, 1/2 in Inscribed Circle, 0.187 in Thickness, 12 Seat, Negative Rake, KRR Chipbreaker, 0.062 in Corner Radius, 0.203 in Hole Dia, Manufacturer's Grade: 3210, ANSI Code: CNMG 434-KRR 3210, ISO Code: CNMG 12 04 16-KRR 3210, 80 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3+TiN Coated, Material Grade: K, For Use On: Cast Iron

Specifications

ANSI Code
CNMG 434-KRR 3210
Chipbreaker
KRR
Corner Radius
0.062 in
Cutting Direction
Neutral
Finish
CVD-TiCN+Al2O3+TiN Coated
For Use On
Cast Iron
Hole Diameter
0.203 in
ISO Code
CNMG 12 04 16-KRR 3210
Included Angle
80 deg
Inscribed Circle
1/2 in
Insert Size
434
Insert Style
CNMG
Manufacturer's Grade
3210
Material
Carbide
Material Grade
K
Maximum Depth of Cut
0.315 in
Rake
Negative
Relief Angle
0 deg
Seat Size
12
Series
T-Max P, T-Max® P
Shape
Rhombic
Thickness
0.187 in

Documents

826242792

Sandvik Coromant 6042792 T-Max P Turning Insert, ANSI Code: CNMG 434-KRR 3210, CNMG Insert, Material Grade: K, 434 Insert, Rhombic Shape, 12 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron, Carbide, Manufacturer's Grade: 3210

Description


Sandvik Coromant Turning Insert, Series: T-Max P, CNMG Insert, 434 Insert, Rhombic, 0.315 in Maximum Depth of Cut, 1/2 in Inscribed Circle, 0.187 in Thickness, 12 Seat, Negative Rake, KRR Chipbreaker, 0.062 in Corner Radius, 0.203 in Hole Dia, Manufacturer's Grade: 3210, ANSI Code: CNMG 434-KRR 3210, ISO Code: CNMG 12 04 16-KRR 3210, 80 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3+TiN Coated, Material Grade: K, For Use On: Cast Iron

Product Number: 826242792

Manufacturer: Sandvik Coromant

Price:

$13.69 / EA
Pack10/PK

MFG #: 6042792

Manufacturer: Sandvik Coromant

Specifications

ANSI Code: CNMG 434-KRR 3210

Chipbreaker: KRR

Corner Radius: 0.062 in

Cutting Direction: Neutral

Finish: CVD-TiCN+Al2O3+TiN Coated

For Use On: Cast Iron

Hole Diameter: 0.203 in

ISO Code: CNMG 12 04 16-KRR 3210

Included Angle: 80 deg

Inscribed Circle: 1/2 in

Insert Size: 434

Insert Style: CNMG

Manufacturer's Grade: 3210

Material: Carbide

Material Grade: K

Maximum Depth of Cut: 0.315 in

Rake: Negative

Relief Angle: 0 deg

Seat Size: 12

Series: T-Max P, T-Max® P

Shape: Rhombic

Thickness: 0.187 in
