Sandvik Coromant 5742778 U-Max Milling Insert, ANSI Code: R215.44-15T316M-WL 4030, R215.44 Insert, 15T316 Insert, Carbide, Manufacturers Grade: 4030, Rectangle Shape, Material Grade: K, N, P

Product Line: Sandvik Coromant

MFG #: 5742778

Sandvik Coromant 5742778 U-Max Milling Insert, ANSI Code: R215.44-15T316M-WL 4030, R215.44 Insert, 15T316 Insert, Carbide, Manufacturers Grade: 4030, Rectangle Shape, Material Grade: K, N, P
Sandvik Coromant 5742778 U-Max Milling Insert, ANSI Code: R215.44-15T316M-WL 4030, R215.44 Insert, 15T316 Insert, Carbide, Manufacturers Grade: 4030, Rectangle Shape, Material Grade: K, N, P
Sandvik Coromant 5742778 U-Max Milling Insert, ANSI Code: R215.44-15T316M-WL 4030, R215.44 Insert, 15T316 Insert, Carbide, Manufacturers Grade: 4030, Rectangle Shape, Material Grade: K, N, P

Your Price

$24.23 / EA
Pack10/PK

Details

Part#826242778

Manufacturer:Sandvik Coromant

MFG #5742778

Sandvik Coromant Milling Insert, Series: U-Max, R215.44 Insert, 15T316 Insert, Rectangle Shape, 0.374 in Inscribed Circle, 0.156 in Thickness, WL Chipbreaker, Positive Rake, 90 deg Lead Angle, 0.158 in Diameter Hole, Manufacturers Grade: 4030, ANSI Code: R215.44-15T316M-WL 4030, ISO Code: R215.44-15T316M-WL 4030, Right Hand of Insert, Carbide, CVD Coated, Material Grade: K, N, P, Cast Iron, Non-Ferrous Metals and Steel Material Application

Specifications

ANSI Code
R215.44-15T316M-WL 4030
Chipbreaker
WL
Country of Origin
SE
Finish
CVD Coated
Hand of Insert
Right
Hole Diameter
0.158 in
Inscribed Circle
0.374 in
Insert Size
15T316
Insert Style
R215.44
ISO Code
R215.44-15T316M-WL 4030
Lead Angle
90 deg
Manufacturer Name
Sandvik Coromant
Manufacturers Grade
4030
Material
Carbide
Material Application
Cast Iron, Non-Ferrous Metals and Steel
Material Grade
K, N, P
Rake
Positive
Series
U-Max
Shape
Rectangle
Thickness
0.156 in

Application

Finishing Applications

Documents

826242778

Sandvik Coromant 5742778 U-Max Milling Insert, ANSI Code: R215.44-15T316M-WL 4030, R215.44 Insert, 15T316 Insert, Carbide, Manufacturers Grade: 4030, Rectangle Shape, Material Grade: K, N, P

Description


Sandvik Coromant Milling Insert, Series: U-Max, R215.44 Insert, 15T316 Insert, Rectangle Shape, 0.374 in Inscribed Circle, 0.156 in Thickness, WL Chipbreaker, Positive Rake, 90 deg Lead Angle, 0.158 in Diameter Hole, Manufacturers Grade: 4030, ANSI Code: R215.44-15T316M-WL 4030, ISO Code: R215.44-15T316M-WL 4030, Right Hand of Insert, Carbide, CVD Coated, Material Grade: K, N, P, Cast Iron, Non-Ferrous Metals and Steel Material Application

Product Number: 826242778

Manufacturer: Sandvik Coromant

Prasdsadice:

$24.23 / EA
Pack10/PK

MFG #: 5742778

Manufacturer: Sandvik Coromant

Specifications

ANSI Code: R215.44-15T316M-WL 4030

Chipbreaker: WL

Country of Origin: SE

Finish: CVD Coated

Hand of Insert: Right

Hole Diameter: 0.158 in

Inscribed Circle: 0.374 in

Insert Size: 15T316

Insert Style: R215.44

ISO Code: R215.44-15T316M-WL 4030

Lead Angle: 90 deg

Manufacturer Name: Sandvik Coromant

Manufacturers Grade: 4030

Material: Carbide

Material Application: Cast Iron, Non-Ferrous Metals and Steel

Material Grade: K, N, P

Rake: Positive

Series: U-Max

Shape: Rectangle

Thickness: 0.156 in

Application

Finishing Applications
