Name: Pramet 6753851 Turning Insert, ANSI Code: TPMR 321-47 T9325, TPMR Insert, Material Grade: K, M, P, S, 321 Insert, Triangular Shape, 16 Seat, Positive Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide
Brand: Dormer Pramet
SKU: DORMER_2005152
Availability: OutOfStock

Dormer Pramet

Pramet 6753851 Turning Insert, ANSI Code: TPMR 321-47 T9325, TPMR Insert, Material Grade: K, M, P, S, 321 Insert, Triangular Shape, 16 Seat, Positive Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

Dormer Pramet

Pramet 6753851 Turning Insert, ANSI Code: TPMR 321-47 T9325, TPMR Insert, Material Grade: K, M, P, S, 321 Insert, Triangular Shape, 16 Seat, Positive Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide

ManufacturerPramet

Part #816093851

MFG #6753851

UPC #3603602892171

Pramet Turning Insert, TPMR Insert, 321 Insert, Triangular, 4 mm Maximum Depth of Cut, 9.525 mm Inscribed Circle, 1/8 in Thickness, 16.5 mm Length, 16 Seat, Positive Rake, 47 Chipbreaker, 0.4 mm Corner Radius, Manufacturers Grade: T9325, ANSI Code: TPMR 321-47 T9325, ISO Code: TPMR 160304E-47 T9325, 60 deg Included Angle, 11 deg Relief Angle, Carbide, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

$ / EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: TPMR 321-47 T9325

Chipbreaker: 47

Corner Radius: 0.4 mm

Country of Origin: CZ

Finish: CVD Coated

For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

Included Angle: 60 deg

Inscribed Circle: 9.525 mm

Insert Size: 321

Insert Style: TPMR

ISO Code: TPMR 160304E-47 T9325

Length: 16.5 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9325

Material: Carbide

Material Grade: K, M, P, S

Maximum Depth of Cut: 4 mm

Rake: Positive

Relief Angle: 11 deg

Seat Size: 16

Shape: Triangular

Thickness: 1/8 in

T9325 grade functionally gradient substrate
Relatively low content of cobalt binder phase
Highly versatile material with very good operational reliability
Medium and higher cutting speed
Special surface finish for coating
Continuous and interrupted cut
Rounded edge

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Pramet Turning Insert, TPMR Insert, 321 Insert, Triangular, 4 mm Maximum Depth of Cut, 9.525 mm Inscribed Circle, 1/8 in Thickness, 16.5 mm Length, 16 Seat, Positive Rake, 47 Chipbreaker, 0.4 mm Corner Radius, Manufacturers Grade: T9325, ANSI Code: TPMR 321-47 T9325, ISO Code: TPMR 160304E-47 T9325, 60 deg Included Angle, 11 deg Relief Angle, Carbide, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

Catalog

Manufacturer Name: Dormer Pramet

ANSI Code: TPMR 321-47 T9325

Chipbreaker: 47

Corner Radius: 0.4 mm

Country of Origin: CZ

Finish: CVD Coated

For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys

Included Angle: 60 deg

Inscribed Circle: 9.525 mm

Insert Size: 321

Insert Style: TPMR

ISO Code: TPMR 160304E-47 T9325

Length: 16.5 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: T9325

Material: Carbide

Material Grade: K, M, P, S

Maximum Depth of Cut: 4 mm

Rake: Positive

Relief Angle: 11 deg

Seat Size: 16

Shape: Triangular

Thickness: 1/8 in

T9325 grade functionally gradient substrate
Relatively low content of cobalt binder phase
Highly versatile material with very good operational reliability
Medium and higher cutting speed
Special surface finish for coating
Continuous and interrupted cut
Rounded edge

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Pramet Turning Insert, TPMR Insert, 321 Insert, Triangular, 4 mm Maximum Depth of Cut, 9.525 mm Inscribed Circle, 1/8 in Thickness, 16.5 mm Length, 16 Seat, Positive Rake, 47 Chipbreaker, 0.4 mm Corner Radius, Manufacturers Grade: T9325, ANSI Code: TPMR 321-47 T9325, ISO Code: TPMR 160304E-47 T9325, 60 deg Included Angle, 11 deg Relief Angle, Carbide, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys
