Name: Pramet 6753708 Negative Milling Insert, ANSI Code: XNGX -54ANSN 8215, XNGX Insert, 0604 Insert, Carbide, Manufacturers Grade: 8215, Wiper Shape
Brand: Dormer Pramet
SKU: DORMER_2006034
Availability: OutOfStock

Dormer Pramet

Pramet 6753708 Negative Milling Insert, ANSI Code: XNGX -54ANSN 8215, XNGX Insert, 0604 Insert, Carbide, Manufacturers Grade: 8215, Wiper Shape

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

Dormer Pramet

Pramet 6753708 Negative Milling Insert, ANSI Code: XNGX -54ANSN 8215, XNGX Insert, 0604 Insert, Carbide, Manufacturers Grade: 8215, Wiper Shape

ManufacturerPramet

Part #816093708

MFG #6753708

UPC #3603602890740

Pramet Milling Insert, Negative, XNGX Insert, 0604 Insert, Wiper, 10.5 mm Inscribed Circle, 5.26 mm Thickness, 0 deg Lead Angle, 3.7 mm Hole Dia, Manufacturers Grade: 8215, ANSI Code: XNGX -54ANSN 8215, ISO Code: XNGX 0604ANSN 8215, Neutral Hand, Carbide, Steel, Cast Iron and Hardened Steel Material Application

$ / EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: XNGX -54ANSN 8215

Country of Origin: CZ

Hand of Insert: Neutral

Hole Diameter: 3.7 mm

Inscribed Circle: 10.5 mm

Insert Size: 0604

Insert Style: XNGX

ISO Code: XNGX 0604ANSN 8215

Lead Angle: 0 deg

Manufacturer Name: Dormer Pramet

Manufacturers Grade: 8215

Material: Carbide

Material Application: Steel, Cast Iron and Hardened Steel

Shape: Wiper

Thickness: 5.26 mm

Type: Negative

Type H submicron substrate with a relatively low cobalt content
High abrasion resistance
New multi layer AlTiN and TiAlSiN based PVD coating
Very good resistance to spreading micro fissures
Suitable for operations with a high thermal load, high cutting speeds and stable machining conditions

Pramet Milling Insert, Negative, XNGX Insert, 0604 Insert, Wiper, 10.5 mm Inscribed Circle, 5.26 mm Thickness, 0 deg Lead Angle, 3.7 mm Hole Dia, Manufacturers Grade: 8215, ANSI Code: XNGX -54ANSN 8215, ISO Code: XNGX 0604ANSN 8215, Neutral Hand, Carbide, Steel, Cast Iron and Hardened Steel Material Application

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Catalog

Manufacturer Name: Dormer Pramet

ANSI Code: XNGX -54ANSN 8215

Country of Origin: CZ

Hand of Insert: Neutral

Hole Diameter: 3.7 mm

Inscribed Circle: 10.5 mm

Insert Size: 0604

Insert Style: XNGX

ISO Code: XNGX 0604ANSN 8215

Lead Angle: 0 deg

Manufacturer Name: Dormer Pramet

Manufacturers Grade: 8215

Material: Carbide

Material Application: Steel, Cast Iron and Hardened Steel

Shape: Wiper

Thickness: 5.26 mm

Type: Negative

Type H submicron substrate with a relatively low cobalt content
High abrasion resistance
New multi layer AlTiN and TiAlSiN based PVD coating
Very good resistance to spreading micro fissures
Suitable for operations with a high thermal load, high cutting speeds and stable machining conditions

Pramet Milling Insert, Negative, XNGX Insert, 0604 Insert, Wiper, 10.5 mm Inscribed Circle, 5.26 mm Thickness, 0 deg Lead Angle, 3.7 mm Hole Dia, Manufacturers Grade: 8215, ANSI Code: XNGX -54ANSN 8215, ISO Code: XNGX 0604ANSN 8215, Neutral Hand, Carbide, Steel, Cast Iron and Hardened Steel Material Application

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Catalog
