Name: Pramet 6755970 Positive Milling Insert, ANSI Code: ZDEW -32 M8345, ZDEW Insert, 120408 Insert, Carbide, Manufacturers Grade: M8345, Curvilinear Square Shape
Brand: Dormer Pramet
SKU: DORMER_2006105
Availability: OutOfStock

Dormer Pramet

Pramet 6755970 Positive Milling Insert, ANSI Code: ZDEW -32 M8345, ZDEW Insert, 120408 Insert, Carbide, Manufacturers Grade: M8345, Curvilinear Square Shape

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Pramet 6755970 Positive Milling Insert, ANSI Code: ZDEW -32 M8345, ZDEW Insert, 120408 Insert, Carbide, Manufacturers Grade: M8345, Curvilinear Square Shape

ManufacturerPramet

Part #816055970

MFG #6755970

UPC #3603602913364

Pramet Milling Insert, Positive, ZDEW Insert, 120408 Insert, Curvilinear Square, 12.7 mm Inscribed Circle, 4.76 mm Thickness, 12.7 mm Length, 0.8 mm Corner Radius, 15 deg Lead Angle, 4.4 mm Hole Dia, Manufacturers Grade: M8345, ANSI Code: ZDEW -32 M8345, ISO Code: ZDEW 120408 M8345, Carbide, Steel, Stainless Steel and Titanium/Super Alloy Material Application

$ / EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

: Manufacturer Name: Dormer Pramet
ANSI Code: ZDEW -32 M8345
Corner Radius: 0.8 mm
Country of Origin: CZ
Finish: CVD Coated
Hole Diameter: 4.4 mm
Inscribed Circle: 12.7 mm
Insert Size: 120408
Insert Style: ZDEW
ISO Code: ZDEW 120408 M8345
Lead Angle: 15 deg
Length: 12.7 mm
Manufacturer Name: Dormer Pramet
Manufacturers Grade: M8345
Material: Carbide
Material Application: Steel, Stainless Steel and Titanium/Super Alloy
Shape: Curvilinear Square
Thickness: 4.76 mm
Type: Positive
: PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov
: Single-sided milling insert ZDEW 1204 with a plane rake surface, special shape and high-feed design for a maximum depth of cut of 1.6 mm, with 0.8 mm corner radius, an indexing accuracy according to ISO-tolerance class-E, M8345 PVD coated WC-Co carbide within ISO-grade range P30-P50 for machining of steel with high feed cutters SZD12.
: Catalog

: Manufacturer Name: Dormer Pramet
ANSI Code: ZDEW -32 M8345
Corner Radius: 0.8 mm
Country of Origin: CZ
Finish: CVD Coated
Hole Diameter: 4.4 mm
Inscribed Circle: 12.7 mm
Insert Size: 120408
Insert Style: ZDEW
ISO Code: ZDEW 120408 M8345
Lead Angle: 15 deg
Length: 12.7 mm
Manufacturer Name: Dormer Pramet
Manufacturers Grade: M8345
Material: Carbide
Material Application: Steel, Stainless Steel and Titanium/Super Alloy
Shape: Curvilinear Square
Thickness: 4.76 mm
Type: Positive
: PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov
: Single-sided milling insert ZDEW 1204 with a plane rake surface, special shape and high-feed design for a maximum depth of cut of 1.6 mm, with 0.8 mm corner radius, an indexing accuracy according to ISO-tolerance class-E, M8345 PVD coated WC-Co carbide within ISO-grade range P30-P50 for machining of steel with high feed cutters SZD12.
: Catalog
