Pramet 6753383 Positive Milling Insert, ANSI Code: ADMX -(2.5)1SR-F 8215, ADMX Insert, 11T304 Insert, Carbide, Manufacturers Grade: 8215, 85 deg Parallelogram Shape

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Pramet 6753383 Positive Milling Insert, ANSI Code: ADMX -(2.5)1SR-F 8215, ADMX Insert, 11T304 Insert, Carbide, Manufacturers Grade: 8215, 85 deg Parallelogram Shape

ManufacturerPramet

Part #816053383

MFG #6753383

UPC #3603602887498

Pramet Milling Insert, Positive, ADMX Insert, 11T304 Insert, 85 deg Parallelogram, 6.53 mm Inscribed Circle, 3.97 mm Thickness, 11 mm Length, F Chipbreaker, 0.4 mm Corner Radius, 15 deg Lead Angle, 2.9 mm Hole Dia, Manufacturers Grade: 8215, ANSI Code: ADMX -(2.5)1SR-F 8215, ISO Code: ADMX 11T304SR-F 8215, Right Hand, Carbide, PVD Coated, Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloy Material Application

$15.95

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: ADMX -(2.5)1SR-F 8215

Chipbreaker: F

Corner Radius: 0.4 mm

Country of Origin: CZ

Finish: PVD Coated

Hand of Insert: Right

Hole Diameter: 2.9 mm

Inscribed Circle: 6.53 mm

Insert Size: 11T304

Insert Style: ADMX

ISO Code: ADMX 11T304SR-F 8215

Lead Angle: 15 deg

Length: 11 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: 8215

Material: Carbide

Material Application: Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloy

Shape: 85 deg Parallelogram

Thickness: 3.97 mm

Type: Positive

Type H submicron substrate with a relatively low cobalt content
High abrasion resistance
Very good resistance to spreading micro fissures
Suitable for operations with a high thermal load, high cutting speeds, stable machining conditions

General Machining Applications

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Catalog

Manufacturer Name: Dormer Pramet

ANSI Code: ADMX -(2.5)1SR-F 8215

Chipbreaker: F

Corner Radius: 0.4 mm

Country of Origin: CZ

Finish: PVD Coated

Hand of Insert: Right

Hole Diameter: 2.9 mm

Inscribed Circle: 6.53 mm

Insert Size: 11T304

Insert Style: ADMX

ISO Code: ADMX 11T304SR-F 8215

Lead Angle: 15 deg

Length: 11 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: 8215

Material: Carbide

Material Application: Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloy

Shape: 85 deg Parallelogram

Thickness: 3.97 mm

Type: Positive

Type H submicron substrate with a relatively low cobalt content
High abrasion resistance
Very good resistance to spreading micro fissures
Suitable for operations with a high thermal load, high cutting speeds, stable machining conditions

General Machining Applications

PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov

Catalog
