Dormer 5970344 A412 Jobber Length Step Drill Bit, 4.5 mm Dia Min Hole, 9 mm Dia Max Hole, HSS, 9 mm Shank

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Dormer Pramet

Dormer 5970344 A412 Jobber Length Step Drill Bit, 4.5 mm Dia Min Hole, 9 mm Dia Max Hole, HSS, 9 mm Shank

ManufacturerDormer

Part #816013650

MFG #0213650

UPC #7320760213650

Dormer Step Drill Bit, Jobber Length, Series: A412, Metric, 4.5 mm Diameter Minimum Hole, 9 mm Diameter Maximum Hole, 84 mm Overall Length, 2.5XD Cutting Depth, 11 mm Step Depth, 40 mm Flute Length, 9 mm Shank, Straight Shank, 118 deg Point, Right Hand Cutting Direction, HSS Cutting Edge, HSS, Steam Tempered, Applicable Materials: Aluminum, Magnesium, Cast Iron, Copper, Nickel, Stainless Steel, Steel Alloy, Titanium and Synthetic Material

$36.53

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

Applicable Materials: Aluminum, Magnesium, Cast Iron, Copper, Nickel, Stainless Steel, Steel Alloy, Titanium and Synthetic Material

Country of Origin: DE

Cutting Depth: 2.5XD

Cutting Direction: Right Hand

Cutting Edge Material: HSS

Drill Diameter Measurement System: Metric

Finish: Steam Tempered

Flute Length: 40 mm

Manufacturer Name: Dormer Pramet

Material: HSS

Maximum Hole Diameter: 9 mm

Minimum Hole Diameter: 4.5 mm

Overall Length: 84 mm

Point Angle: 118 deg

Series: A412

Shank Size: 9 mm

Shank Type: Straight

Step Depth: 11 mm

Type: Jobber Length

No coolant channel
Included Angle 90 deg

General Purpose Applications

Catalog

Manufacturer Name: Dormer Pramet

Applicable Materials: Aluminum, Magnesium, Cast Iron, Copper, Nickel, Stainless Steel, Steel Alloy, Titanium and Synthetic Material

Country of Origin: DE

Cutting Depth: 2.5XD

Cutting Direction: Right Hand

Cutting Edge Material: HSS

Drill Diameter Measurement System: Metric

Finish: Steam Tempered

Flute Length: 40 mm

Manufacturer Name: Dormer Pramet

Material: HSS

Maximum Hole Diameter: 9 mm

Minimum Hole Diameter: 4.5 mm

Overall Length: 84 mm

Point Angle: 118 deg

Series: A412

Shank Size: 9 mm

Shank Type: Straight

Step Depth: 11 mm

Type: Jobber Length

No coolant channel
Included Angle 90 deg

General Purpose Applications

Catalog
