Name: Seco Niagara Cutter 17013520 REM710 Non-Center Cutting Single End Stub Length End Mill, 1-1/2 in Dia Cutter, 0.04 in Corner Radius, 8 in Length of Cut, 6 Flutes, 1-1/4 in Dia Shank, 10-1/2 in OAL, TiCN
Brand: Seco Tools
SKU: Seco_009864
Availability: OutOfStock

Seco Tools

Seco Niagara Cutter 17013520 REM710 Non-Center Cutting Single End Stub Length End Mill, 1-1/2 in Dia Cutter, 0.04 in Corner Radius, 8 in Length of Cut, 6 Flutes, 1-1/4 in Dia Shank, 10-1/2 in OAL, TiCN

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Seco Tools

Seco Niagara Cutter 17013520 REM710 Non-Center Cutting Single End Stub Length End Mill, 1-1/2 in Dia Cutter, 0.04 in Corner Radius, 8 in Length of Cut, 6 Flutes, 1-1/4 in Dia Shank, 10-1/2 in OAL, TiCN

ManufacturerSeco

Part #803669323

MFG #17013520

Seco Niagara Cutter End Mill, Non-Center Cutting Single End Stub Length, Series: REM710, 1-1/2 in Diameter Cutter, 0.04 in Corner Radius, 10-1/2 in Overall Length, 8 in Length of Cut, 6 Flutes, Spiral Flute, 1-1/4 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Weldon Flat Shank, ANSI Code: REM710-1.500-P10-C040.3-Z6, ISO Code: REM7101.500P10C040.3Z6, M42 HSS-Co 8, TiCN

$ / EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

: Manufacturer Name: Seco Tools
ANSI Code: REM710-1.500-P10-C040.3-Z6
Corner Radius: 0.04 in
Country of Origin: US
Cutter Diameter: 1-1/2 in
Cutting Direction: Right Hand
Finish: TiCN, TiCN Coated
Flute Type: Spiral
Helix Angle: 30 deg
ISO Code: REM7101.500P10C040.3Z6
Length of Cut: 8 in
Manufacturer Name: Seco Tools
Material: M42 HSS-Co 8
Number of Flutes: 6
Overall Length: 10-1/2 in
Series: REM710
Shank Diameter: 1-1/4 in
Shank Type: Weldon Flat
Type: Non-Center Cutting Single End Stub Length
: The Solid end mill REM7101.500P10C040.3Z6 TICN features a REM710 cutting geometry type and a maximum cutting diameter of 1.5 inch. With a shank diameter of 1.25 inch and a Weldon shank type, the milling cutter has six peripheral cutting edges and a corner radius of 0 inch. It supports a maximum depth of cut in the feed direction side of 8 inch. The grade used is TICN. This product can be recycled. Get in contact with your sales representative to discuss next steps for more circularity. Check out more products for machine side or workpiece side options within our range to complement this product. With our complementing services, you can make the most of your tool. Download the Seco Assistant to get access to comprehensive tooling information. This text was generated and translated with the assistance of AI and may contain inaccuracies.
: Catalog

: Manufacturer Name: Seco Tools
ANSI Code: REM710-1.500-P10-C040.3-Z6
Corner Radius: 0.04 in
Country of Origin: US
Cutter Diameter: 1-1/2 in
Cutting Direction: Right Hand
Finish: TiCN, TiCN Coated
Flute Type: Spiral
Helix Angle: 30 deg
ISO Code: REM7101.500P10C040.3Z6
Length of Cut: 8 in
Manufacturer Name: Seco Tools
Material: M42 HSS-Co 8
Number of Flutes: 6
Overall Length: 10-1/2 in
Series: REM710
Shank Diameter: 1-1/4 in
Shank Type: Weldon Flat
Type: Non-Center Cutting Single End Stub Length
: The Solid end mill REM7101.500P10C040.3Z6 TICN features a REM710 cutting geometry type and a maximum cutting diameter of 1.5 inch. With a shank diameter of 1.25 inch and a Weldon shank type, the milling cutter has six peripheral cutting edges and a corner radius of 0 inch. It supports a maximum depth of cut in the feed direction side of 8 inch. The grade used is TICN. This product can be recycled. Get in contact with your sales representative to discuss next steps for more circularity. Check out more products for machine side or workpiece side options within our range to complement this product. With our complementing services, you can make the most of your tool. Download the Seco Assistant to get access to comprehensive tooling information. This text was generated and translated with the assistance of AI and may contain inaccuracies.
: Catalog
