JET 333605 Single Leverage Arbor Press, 0.5 ton Capacity, 3/8 in Width/Dia Ram, 6-5/8 in Max Work Width/Dia, 4-3/4 in H Max Work, 4 x 9-1/2 in Base

Manufacturer: JET
MFG #: 333605
JET 333605 Single Leverage Arbor Press, 0.5 ton Capacity, 3/8 in Width/Dia Ram, 6-5/8 in Max Work Width/Dia, 4-3/4 in H Max Work, 4 x 9-1/2 in Base

Your Price

$90.86 / EA

JET 333605 Single Leverage Arbor Press, 0.5 ton Capacity, 3/8 in Width/Dia Ram, 6-5/8 in Max Work Width/Dia, 4-3/4 in H Max Work, 4 x 9-1/2 in Base

Manufacturer: JET
MFG #: 333605

Your Price

$90.86 / EA

Details

Part#720369202

Manufacturer:JPW Industries

UPC:662755692024

MFG #333605

JET Arbor Press, Single Leverage, 0.5 ton, 3/8 in Ram, 3-15/16 in Throat Depth, 3-1/2 in Stroke, 4 x 9-1/2 in Base, 4-3/4 in Maximum Work Height, 6-5/8 in Max Work Width/Diameter, 10-3/8 in Overall Height, Manual Operation, Heavy Ductile Cast Iron, 9-5/16 in L x 6-5/8 in W

Specifications

Base Size
4 x 9-1/2 in
Capacity
0.5 ton
Dimensions
9-5/16 in L x 6-5/8 in W
Material
Heavy Ductile Cast Iron
Maximum Work Height
4-3/4 in
Maximum Work Width/Diameter
6-5/8 in
Operation Type
Manual
Overall Height
10-3/8 in
Ram Width/Diameter
3/8 in
Stroke Length
3-1/2 in
Throat Depth
3-15/16 in
Type
Single Leverage

Item Features

  • Precision cut steel rams and pinions for accurate operation
  • Tables and slotted table-plates are flat and parallel to provide accurate support

Item Includes

Anvil

720369202

JET 333605 Single Leverage Arbor Press, 0.5 ton Capacity, 3/8 in Width/Dia Ram, 6-5/8 in Max Work Width/Dia, 4-3/4 in H Max Work, 4 x 9-1/2 in Base

Description


JET Arbor Press, Single Leverage, 0.5 ton, 3/8 in Ram, 3-15/16 in Throat Depth, 3-1/2 in Stroke, 4 x 9-1/2 in Base, 4-3/4 in Maximum Work Height, 6-5/8 in Max Work Width/Diameter, 10-3/8 in Overall Height, Manual Operation, Heavy Ductile Cast Iron, 9-5/16 in L x 6-5/8 in W

Product Number: 720369202

Manufacturer: JET

Price:

$90.86 / EA

MFG #: 333605

Manufacturer: JPW Industries

UPC: 662755692024

Specifications

Base Size: 4 x 9-1/2 in

Capacity: 0.5 ton

Dimensions: 9-5/16 in L x 6-5/8 in W

Material: Heavy Ductile Cast Iron

Maximum Work Height: 4-3/4 in

Maximum Work Width/Diameter: 6-5/8 in

Operation Type: Manual

Overall Height: 10-3/8 in

Ram Width/Diameter: 3/8 in

Stroke Length: 3-1/2 in

Throat Depth: 3-15/16 in

Type: Single Leverage

Item Includes

Anvil
