Name: Seco 02426811 Milling Insert, ANSI Code: SEEX1204AFN-M10 F40M, SEEX Insert, 1204 Insert, Carbide, Manufacturers Grade: F40M, Squared Shape, Material Grade: C5
Brand: Seco Tools
SKU: SECO_TOOLS_Q2_18_100496
Availability: OutOfStock

Seco Tools

Seco 02426811 Milling Insert, ANSI Code: SEEX1204AFN-M10 F40M, SEEX Insert, 1204 Insert, Carbide, Manufacturers Grade: F40M, Squared Shape, Material Grade: C5

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Seco Tools

Seco 02426811 Milling Insert, ANSI Code: SEEX1204AFN-M10 F40M, SEEX Insert, 1204 Insert, Carbide, Manufacturers Grade: F40M, Squared Shape, Material Grade: C5

ManufacturerSeco

Part #288504943

MFG #02426811

Seco Milling Insert, SEEX Insert, 1204 Insert, Squared, 12.7 mm Inscribed Circle, 4.76 mm Thickness, 12.7 mm Width, 12.7 mm Length, M10 Chipbreaker, Manufacturers Grade: F40M, ANSI Code: SEEX1204AFN-M10 F40M, Neutral Hand, Carbide, TiAlN/TiN, Material Grade: C5, Cast Iron, Non-Ferrous Metals, Plastics and Tough-to-Machine Materials Material Application

$ / EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

: Manufacturer Name: Seco Tools
ANSI Code: SEEX1204AFN-M10 F40M
Chipbreaker: M10
Country of Origin: SE
Finish: PVD-TiAlN+TiN Coated, TiAlN/TiN
Hand of Insert: Neutral
Inscribed Circle: 12.7 mm
Insert Size: 1204
Insert Style: SEEX
Length: 12.7 mm
Manufacturer Name: Seco Tools
Manufacturers Grade: F40M
Material: Carbide
Material Application: Cast Iron, Non-Ferrous Metals, Plastics and Tough-to-Machine Materials
Material Grade: C5
Shape: Squared
Thickness: 4.76 mm
Width: 12.7 mm
: The Face milling insert SEEX1204AFN-M10 F40M features four cutting edges with a clearance angle major of 20 degrees. It is a single-sided insert with a carbide PVD grade. The wiper edge length measures 1.5 mm, and the corner radius is 1.12 mm. The insert has a neutral hand orientation and connects to the machine side via a .53-12 connection. It is primarily designed for stainless steel, superalloys, and titanium, with partial applicability to steel and non-ferrous materials. This product can be recycled. Get in contact with your sales representative to discuss next steps for more circularity. Check out more products for machine side or workpiece side options within our range to complement this product. With our complementing services, you can make the most of your tool. Download the Seco Assistant to get access to comprehensive tooling information. This text was generated and translated with the assistance of AI and may contain inaccuracies.
: Catalog
Video Link

: Manufacturer Name: Seco Tools
ANSI Code: SEEX1204AFN-M10 F40M
Chipbreaker: M10
Country of Origin: SE
Finish: PVD-TiAlN+TiN Coated, TiAlN/TiN
Hand of Insert: Neutral
Inscribed Circle: 12.7 mm
Insert Size: 1204
Insert Style: SEEX
Length: 12.7 mm
Manufacturer Name: Seco Tools
Manufacturers Grade: F40M
Material: Carbide
Material Application: Cast Iron, Non-Ferrous Metals, Plastics and Tough-to-Machine Materials
Material Grade: C5
Shape: Squared
Thickness: 4.76 mm
Width: 12.7 mm
: The Face milling insert SEEX1204AFN-M10 F40M features four cutting edges with a clearance angle major of 20 degrees. It is a single-sided insert with a carbide PVD grade. The wiper edge length measures 1.5 mm, and the corner radius is 1.12 mm. The insert has a neutral hand orientation and connects to the machine side via a .53-12 connection. It is primarily designed for stainless steel, superalloys, and titanium, with partial applicability to steel and non-ferrous materials. This product can be recycled. Get in contact with your sales representative to discuss next steps for more circularity. Check out more products for machine side or workpiece side options within our range to complement this product. With our complementing services, you can make the most of your tool. Download the Seco Assistant to get access to comprehensive tooling information. This text was generated and translated with the assistance of AI and may contain inaccuracies.
: Catalog
Video Link
