SGS 34631 47B Ball Nose End Fractional High Performance Regular Length High Performance End Mill, 3/16 in Dia Cutter, 9/16 in Length of Cut, 2 Flutes, 3/16 in Dia Shank, 2 in OAL, Uncoated

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

KYOCERA SGS Precision tools, Inc.

SGS 34631 47B Ball Nose End Fractional High Performance Regular Length High Performance End Mill, 3/16 in Dia Cutter, 9/16 in Length of Cut, 2 Flutes, 3/16 in Dia Shank, 2 in OAL, Uncoated

ManufacturerSGS

Part #069934631

MFG #34631

UPC #691781346311

SGS High Performance End Mill, Ball Nose End Fractional High Performance Regular Length, Series: 47B, 3/16 in Diameter Cutter, 2 in Overall Length, 9/16 in Length of Cut, 2 Flutes, Spiral Flute, 3/16 in Shank Diameter, Right Hand Cutting Direction, 35 deg Helix Angle, Straight Shank, 1.438 in Shank Length, Micrograin Solid Carbide, Uncoated

$26.88

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: KYOCERA SGS Precision tools, Inc.

Country of Origin: US

Cutter Diameter: 3/16 in

Cutting Direction: Right Hand

Finish: Uncoated

Flute Type: Spiral

Helix Angle: 35 deg

Length of Cut: 9/16 in

Manufacturer Name: KYOCERA Precision Tools, KYOCERA SGS Precision tools, Inc.

Material: Micrograin Solid Carbide

Number of Flutes: 2

Overall Length: 2 in

Series: 47B

Shank Diameter: 3/16 in

Shank Length: 1.438 in

Shank Type: Straight

Type: Ball Nose End Fractional High Performance Regular Length

Circular land reduces edge aggressiveness for varied speed and feed rates
2 Flutes effectively manage the large size and volume of chips produced during the aggressive machining process
Excellent balance at high speeds and aggressive plunging capability
Recommended for materials <= 150 Bhn (<= 7 HRc)

SGS High Performance End Mill, Ball Nose End Fractional High Performance Regular Length, Series: 47B, 3/16 in Diameter Cutter, 2 in Overall Length, 9/16 in Length of Cut, 2 Flutes, Spiral Flute, 3/16 in Shank Diameter, Right Hand Cutting Direction, 35 deg Helix Angle, Straight Shank, 1.438 in Shank Length, Micrograin Solid Carbide, Uncoated

Manufacturer Name: KYOCERA SGS Precision tools, Inc.

Country of Origin: US

Cutter Diameter: 3/16 in

Cutting Direction: Right Hand

Finish: Uncoated

Flute Type: Spiral

Helix Angle: 35 deg

Length of Cut: 9/16 in

Manufacturer Name: KYOCERA Precision Tools, KYOCERA SGS Precision tools, Inc.

Material: Micrograin Solid Carbide

Number of Flutes: 2

Overall Length: 2 in

Series: 47B

Shank Diameter: 3/16 in

Shank Length: 1.438 in

Shank Type: Straight

Type: Ball Nose End Fractional High Performance Regular Length

Circular land reduces edge aggressiveness for varied speed and feed rates
2 Flutes effectively manage the large size and volume of chips produced during the aggressive machining process
Excellent balance at high speeds and aggressive plunging capability
Recommended for materials <= 150 Bhn (<= 7 HRc)

SGS High Performance End Mill, Ball Nose End Fractional High Performance Regular Length, Series: 47B, 3/16 in Diameter Cutter, 2 in Overall Length, 9/16 in Length of Cut, 2 Flutes, Spiral Flute, 3/16 in Shank Diameter, Right Hand Cutting Direction, 35 deg Helix Angle, Straight Shank, 1.438 in Shank Length, Micrograin Solid Carbide, Uncoated
