TPI Corporation | TPI ACH20 1-Phase Assembled Standard Fan Head, 22 in Blade, 5600 cfm High, 4100 cfm Low Flow Rate, 120 VAC, 2.4 A

TPI ACH20 1-Phase Assembled Standard Fan Head, 22 in Blade, 5600 cfm High, 4100 cfm Low Flow Rate, 120 VAC, 2.4 A

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

TPI Corporation

TPI ACH20 1-Phase Assembled Standard Fan Head, 22 in Blade, 5600 cfm High, 4100 cfm Low Flow Rate, 120 VAC, 2.4 A

ManufacturerTPI

Part #633486847

MFG #ACH20

UPC #686334868471

TPI Fan Head, 1-Phase Assembled Standard, 22 in Blade, 5600 cfm High, 4100 cfm Low, 1100 rpm High, 900 rpm Low Speed, 1/4 hp Power, 120 VAC, 2.4 A, 2 Speed, Pull Chain Control, Paddle Blade, Aluminum Blade, Split Capacitor Motor, Steel Housing Material, SJT 12 ft Cord, 22 in Dia x 14-1/2 in D Dimensions, Domestic

$369.53

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: TPI Corporation

Amperage Rating: 2.4 A

Blade Material: Aluminum

Blade Size: 22 in

Blade Type: Paddle

Control Type: Pull Chain

Cord Type: SJT 12 ft

Country of Origin: US

Dimensions: 22 in Dia x 14-1/2 in D

Domestic/Import: Domestic

Flow Rate: 5600 cfm High, 4100 cfm Low

Housing Material: Steel

Manufacturer Name: TPI Corporation

Motor Type: Split Capacitor

Number of Speeds: 2

Power Rating: 1/4 hp

Speed: 1100 rpm High, 900 rpm Low

Type: 1-Phase Assembled Standard

Voltage Rating: 120 VAC

Steel hub/spider aluminum paddle blades
Coated steel guards
Ball bearing, permanent split capacitor, totally enclosed and permanently lubricated motor
#48 motor frame
1/2 in Dia shaft motor
Motor drive
Use with any TPI ACM/CACM mount

cETLus Listed|OSHA Compliant|PROP65: This product can expose you to chemicals including nickel which is known to the State of California to cause cancer|and chromium which is known to the State of California to cause birth defects and/or reproductive harm. For more information go to www.P65Warnings.cs.gov

Indoor-Commercial and Industrial Applications

Catalog

Specification Sheet

Warranty Information

Manufacturer Name: TPI Corporation

Amperage Rating: 2.4 A

Blade Material: Aluminum

Blade Size: 22 in

Blade Type: Paddle

Control Type: Pull Chain

Cord Type: SJT 12 ft

Country of Origin: US

Dimensions: 22 in Dia x 14-1/2 in D

Domestic/Import: Domestic

Flow Rate: 5600 cfm High, 4100 cfm Low

Housing Material: Steel

Manufacturer Name: TPI Corporation

Motor Type: Split Capacitor

Number of Speeds: 2

Power Rating: 1/4 hp

Speed: 1100 rpm High, 900 rpm Low

Type: 1-Phase Assembled Standard

Voltage Rating: 120 VAC

Steel hub/spider aluminum paddle blades
Coated steel guards
Ball bearing, permanent split capacitor, totally enclosed and permanently lubricated motor
#48 motor frame
1/2 in Dia shaft motor
Motor drive
Use with any TPI ACM/CACM mount

cETLus Listed|OSHA Compliant|PROP65: This product can expose you to chemicals including nickel which is known to the State of California to cause cancer|and chromium which is known to the State of California to cause birth defects and/or reproductive harm. For more information go to www.P65Warnings.cs.gov

Indoor-Commercial and Industrial Applications

Catalog

Specification Sheet

Warranty Information
