Seco Tools | Seco 02730472 SD22 Micro Drill, 0.26 mm Drill - Metric, 0.0102 in Drill - Decimal Inch, 3 mm Shank, 2 Flutes

Seco 02730472 SD22 Micro Drill, 0.26 mm Drill - Metric, 0.0102 in Drill - Decimal Inch, 3 mm Shank, 2 Flutes

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Seco Tools

Seco 02730472 SD22 Micro Drill, 0.26 mm Drill - Metric, 0.0102 in Drill - Decimal Inch, 3 mm Shank, 2 Flutes

ManufacturerSeco

Part #288563387

MFG #02730472

Seco Micro Drill, Series: MDT, 0.26 mm Drill Size - Metric, 0.0102 in Drill Size - Decimal Inch, 38 mm Overall Length, 2xD Cutting Depth, 2 Flutes, Spiral Flute, 0.9 mm Flute Length, 3 mm Shank, Cylindrical Shank, 130 deg Point, Self-Centering Point, Right Hand Cutting, Solid Carbide Cutting Edge, Solid Carbide, Uncoated, Applicable Materials: Cast Iron, Non-Ferrous Materials and Plastic

$30.30

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Seco Tools

Applicable Materials: Cast Iron, Non-Ferrous Materials and Plastic

Country of Origin: CH

Cutting Depth: 2xD

Cutting Direction: Right Hand

Cutting Edge Material: Solid Carbide

Drill Size - Decimal Inch: 0.0102 in

Drill Size - Metric: 0.26 mm

Finish: Uncoated

Flute Length: 0.9 mm

Flute Type: Spiral

Manufacturer Name: Seco Tools

Material: Solid Carbide

Number of Flutes: 2

Overall Length: 38 mm

Point Angle: 130 deg

Point Type: Self-Centering

Series: SD22

Shank Size: 3 mm

Shank Type: Cylindrical

GDG Code: B79
Solid carbide provides better rigidity than high speed steel, it is extremely heat resistant and used for high speed applications
65 deg tool cutting edge
0.52 mm L usable
Spiral flutes are constructed of a higher flute angle to remove chips easier
High productivity and low cost per hole
Up to 0.7 mm/r cutting feed
Up to 220 m/min cutting speed
High hole quality with no need for centre drilling operations
Strong cutting edge
High cutting edge quality
High strength carbide rod minimises risk for breakages
Protective corner chamfer
Tapered web configuration
External Coolant
Coolant Recommendations - Recommended emulsion mix 6-8%, when drilling in stainless steels, superalloys and high strength steels a mix of 10% is recommended
ANSI Code: SD22-0.26-0.52-3R1
ISO Code: SD22-0.26-0.52-3R1

Seco Feedmax is our latest generation of high performance solid carbide drills. They offer a unique combination of state-of-the-art carbide, coating and geometry technology. SD22 and SD26 are a new range of small, highly productive solid carbide micro drills designed for applications in the automotive and medical industries, along with many users in small part production in the engineering industry.

Manufacturer Name: Seco Tools

Applicable Materials: Cast Iron, Non-Ferrous Materials and Plastic

Country of Origin: CH

Cutting Depth: 2xD

Cutting Direction: Right Hand

Cutting Edge Material: Solid Carbide

Drill Size - Decimal Inch: 0.0102 in

Drill Size - Metric: 0.26 mm

Finish: Uncoated

Flute Length: 0.9 mm

Flute Type: Spiral

Manufacturer Name: Seco Tools

Material: Solid Carbide

Number of Flutes: 2

Overall Length: 38 mm

Point Angle: 130 deg

Point Type: Self-Centering

Series: SD22

Shank Size: 3 mm

Shank Type: Cylindrical

GDG Code: B79
Solid carbide provides better rigidity than high speed steel, it is extremely heat resistant and used for high speed applications
65 deg tool cutting edge
0.52 mm L usable
Spiral flutes are constructed of a higher flute angle to remove chips easier
High productivity and low cost per hole
Up to 0.7 mm/r cutting feed
Up to 220 m/min cutting speed
High hole quality with no need for centre drilling operations
Strong cutting edge
High cutting edge quality
High strength carbide rod minimises risk for breakages
Protective corner chamfer
Tapered web configuration
External Coolant
Coolant Recommendations - Recommended emulsion mix 6-8%, when drilling in stainless steels, superalloys and high strength steels a mix of 10% is recommended
ANSI Code: SD22-0.26-0.52-3R1
ISO Code: SD22-0.26-0.52-3R1
