Haimer 75.250.DL20 Short Conical Extension With Safe-Lock, DL20 Shank Connection, 19.3 mm Dia Nose

ManufacturerHaimer

Part #129501717

MFG #75.250.DL20

Haimer Conical Extension, Short, Series: VDS402F, 3 mm Hole Dia, 19.3 mm Nose Dia, 95 mm Overall Length, 25 mm Overall Dia, DL20 Shank Connection

$481.00

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Haimer

Hole Diameter: 3 mm

Nose Diameter: 19.3 mm

Overall Diameter: 25 mm

Overall Length: 95 mm

Shank Connection Size: DL20

Type: Short

Superior rigidity of the interface allows for greater depths of cut up to 1.5xD in full slotting
The most robust modular system ever developed
FEA based design ensures that stress levels in the interface remain below critical values even at elevated loads
The double cone surfaces, combined with an additional third supporting pilot, delivers high stiffness and accuracy
H6 shank tolerance
With inner coolant bore
