Emuge AU921400.0112 Druck STEEL-SN AU921400 Form C Reduced Shank Thread Forming Tap, M12x1.75 Thread

ManufacturerEmuge

Part #826500377

MFG #AU921400.0112

Emuge Thread Forming Tap, Form C Reduced Shank, Series: Druck STEEL-SN AU921400, Measurement System: Metric, M12x1.75, Coarse, Modified Bottoming Chamfer, 0.948 in Thread Length, 3.38 in Overall Length, Right Hand Cutting, Class of Fit: 6HX, 0.367 in Shank Dia, 2.4 in Shank Length, 11.25 mm Tap Drill, 0.275 in Square Size, HSS-E, TiN Coated

$115.12

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Emuge-Franken

Chamfer Type: Modified Bottoming

Class of Fit: 6HX

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: TiN Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Measurement System: Metric

Overall Length: 3.38 in

Series: Druck STEEL-SN AU921400

Shank Diameter: 0.367 in

Shank Length: 2.4 in

Square Size: 0.275 in

Tap Drill Size: 11.25 mm

Thread Length: 0.948 in

Thread Size: M12x1.75

Thread Standard: Coarse

Type: Form C Reduced Shank

Druck steel roll form tap is a universal design for the chipless production of internal threads, blind and though hole
TiN coated for additional tool life
With or without lube grooves
DIN/DIN or the shorter ANSI/ANSI standard dimensions for overall length and shank size

ANSI/ANSI Specified|DIN 13|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Emuge Thread Forming Tap, Form C Reduced Shank, Series: Druck STEEL-SN AU921400, Measurement System: Metric, M12x1.75, Coarse, Modified Bottoming Chamfer, 0.948 in Thread Length, 3.38 in Overall Length, Right Hand Cutting, Class of Fit: 6HX, 0.367 in Shank Dia, 2.4 in Shank Length, 11.25 mm Tap Drill, 0.275 in Square Size, HSS-E, TiN Coated

Manufacturer Name: Emuge-Franken

Chamfer Type: Modified Bottoming

Class of Fit: 6HX

Country of Origin: DE

Cutting Direction: Right Hand

Finish/Coating: TiN Coated

Manufacturer Name: Emuge-Franken

Material: HSS-E

Measurement System: Metric

Overall Length: 3.38 in

Series: Druck STEEL-SN AU921400

Shank Diameter: 0.367 in

Shank Length: 2.4 in

Square Size: 0.275 in

Tap Drill Size: 11.25 mm

Thread Length: 0.948 in

Thread Size: M12x1.75

Thread Standard: Coarse

Type: Form C Reduced Shank

Druck steel roll form tap is a universal design for the chipless production of internal threads, blind and though hole
TiN coated for additional tool life
With or without lube grooves
DIN/DIN or the shorter ANSI/ANSI standard dimensions for overall length and shank size

ANSI/ANSI Specified|DIN 13|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Emuge Thread Forming Tap, Form C Reduced Shank, Series: Druck STEEL-SN AU921400, Measurement System: Metric, M12x1.75, Coarse, Modified Bottoming Chamfer, 0.948 in Thread Length, 3.38 in Overall Length, Right Hand Cutting, Class of Fit: 6HX, 0.367 in Shank Dia, 2.4 in Shank Length, 11.25 mm Tap Drill, 0.275 in Square Size, HSS-E, TiN Coated
