Pramet 6753384 Positive Milling Insert, ANSI Code: ADMX -(2.5)1SR-M 8215, ADMX Insert, 11T304 Insert, Carbide, Manufacturers Grade: 8215, 85 deg Parallelogram Shape

ManufacturerPramet

Part #816053384

MFG #6753384

UPC #3603602887504

Pramet Milling Insert, Positive, ADMX Insert, 11T304 Insert, 85 deg Parallelogram, 6.53 mm Inscribed Circle, 3.97 mm Thickness, 11 mm Length, M Chipbreaker, 0.4 mm Corner Radius, 15 deg Lead Angle, 2.9 mm Hole Dia, Manufacturers Grade: 8215, ANSI Code: ADMX -(2.5)1SR-M 8215, ISO Code: ADMX 11T304SR-M 8215, Right Hand, Carbide, PVD Coated, Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloy Material Application

$15.95

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Dormer Pramet

ANSI Code: ADMX -(2.5)1SR-M 8215

Chipbreaker: M

Corner Radius: 0.4 mm

Country of Origin: CZ

Finish: PVD Coated

Hand of Insert: Right

Hole Diameter: 2.9 mm

Inscribed Circle: 6.53 mm

Insert Size: 11T304

Insert Style: ADMX

ISO Code: ADMX 11T304SR-M 8215

Lead Angle: 15 deg

Length: 11 mm

Manufacturer Name: Dormer Pramet

Manufacturers Grade: 8215

Material: Carbide

Material Application: Hardened Steel, Cast Iron, Stainless Steel, Aluminum, Steel and Titanium/Super Alloy

Shape: 85 deg Parallelogram

Thickness: 3.97 mm

Type: Positive

Type H submicron substrate with a relatively low cobalt content
High abrasion resistance
Very good resistance to spreading micro fissures
Suitable for operations with a high thermal load, high cutting speeds, stable machining conditions

General Machining Applications
