3M 7100018269 DF Series Support Basket, For Use With 3M DF Series Filter System, #2, 316 Stainless Steel
Pricing Notice
Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.
Terms of SaleHave a Question About a Product?
Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.
Contact Us3M 7100018269 DF Series Support Basket, For Use With 3M DF Series Filter System, #2, 316 Stainless Steel
Manufacturer3M
Part #113838237
MFG #7100018269
UPC #016145258664
3M, 7100018269, Support Basket, Series: DF Series, For Use With: 3M DF Series Filter System, Specifications: #2, 316 Stainless Steel, 7 in Dia Dimensions
$457.14
 / EAKnowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.
- Manufacturer Name:Â 3MCountry of Origin:Â TWDimensions:Â 7 in DiaManufacturer Name:Â 3MMaterial:Â 316 Stainless SteelSeries:Â DF SeriesSpecifications:Â #2Suitable For Use With:Â 3M DF Series Filter System
- Graded porosity filter medium provides up to 4 times more life than most conventional bag filters for fewer change outs
- Easily retrofits standard bag filter housings
- Reduced filter changes help minimize product loss, labor, disposal costs and operator exposure
- Cartridge design reduces filter medium rupture, contaminant bypass and unloading
- Simplifies filter installation, removal and disposal
- The 3M DF series filter element is a proven alternative to most conventional bag filters. This filter is a true graded porosity media structure that provides a 62% increase in surface area compared to a standard #2 bag and up to 4 times more service life. The 3M DF series filter media consists of 2 layers with the first layer being open to remove the larger contaminants while the second layer is tighter to remove the smaller contaminants. The graded porosity structure provides greater contaminant holding capacity and longer life than conventional single layer media. Compared to conventional felt filter bags, 3M DF series filter element provide up to 4 times the service life, superior contaminant reduction efficiency, enhanced flow per filter and reduced losses associated with frequent filter change outs. Geometry the 3M DF series filter element consists of two cylinders bonded to a top plate and a lower seal plate. As fluid enters the top of the filter through flow channels in the top plate, it flows between the inner and outer media cylinders. Then it passes through the media and support basket and into the clean chamber of the filter housing. The design incorporates an innovative geometry of both bag filter and restrainer basket, giving complete 3-dimensional support of the media. This eliminates the potential for bag filter rupture and the resulting gross contamination of the downstream effluent. The 3M DF series filter element design reduces hold up fluid volume by 67% compared to conventional filter bags, which helps minimize worker exposure to process fluids due to less frequent bag change outs. 3M DF series filter best features 100% downstream support of the filter element eliminates filter rupture, contaminant bypass and unloading Allows operation to higher differential pressures before filter change out superior flow characteristics maximizes utilization of filter surface area and maintains low operating pressure drop reduces flow per unit area (flux) for improved effluent quality greater media surface area achieves up to four times the service life as compared to conventional filter bags Improves the retention efficiency of the bag filter Greater contaminant holding capacity media layers of different porosities are combined to form a graded porosity structure each nominally rated filter medium has been optimized to achieve the longest service life advanced thermal sealing processes are used to weld the side seams to form the bag and secure the sealing ring. Thermal singe treatment of the exterior surface prevents material fibers from migrating into the clean filtered process media. Each grade of the 3M DF series filter element is manufactured from high performance fibers that are selected, based on extensive media performance testing. No adhesives, binders or silicone are used in the manufacturing processes. Applications include Industrial waters lubricants chemicals petrochemicals food wine filtration beer micro filtration process water pharmaceuticals electronics purification water treatment.
- Manufacturer Name:Â 3MCountry of Origin:Â TWDimensions:Â 7 in DiaManufacturer Name:Â 3MMaterial:Â 316 Stainless SteelSeries:Â DF SeriesSpecifications:Â #2Suitable For Use With:Â 3M DF Series Filter System
- Graded porosity filter medium provides up to 4 times more life than most conventional bag filters for fewer change outs
- Easily retrofits standard bag filter housings
- Reduced filter changes help minimize product loss, labor, disposal costs and operator exposure
- Cartridge design reduces filter medium rupture, contaminant bypass and unloading
- Simplifies filter installation, removal and disposal
- The 3M DF series filter element is a proven alternative to most conventional bag filters. This filter is a true graded porosity media structure that provides a 62% increase in surface area compared to a standard #2 bag and up to 4 times more service life. The 3M DF series filter media consists of 2 layers with the first layer being open to remove the larger contaminants while the second layer is tighter to remove the smaller contaminants. The graded porosity structure provides greater contaminant holding capacity and longer life than conventional single layer media. Compared to conventional felt filter bags, 3M DF series filter element provide up to 4 times the service life, superior contaminant reduction efficiency, enhanced flow per filter and reduced losses associated with frequent filter change outs. Geometry the 3M DF series filter element consists of two cylinders bonded to a top plate and a lower seal plate. As fluid enters the top of the filter through flow channels in the top plate, it flows between the inner and outer media cylinders. Then it passes through the media and support basket and into the clean chamber of the filter housing. The design incorporates an innovative geometry of both bag filter and restrainer basket, giving complete 3-dimensional support of the media. This eliminates the potential for bag filter rupture and the resulting gross contamination of the downstream effluent. The 3M DF series filter element design reduces hold up fluid volume by 67% compared to conventional filter bags, which helps minimize worker exposure to process fluids due to less frequent bag change outs. 3M DF series filter best features 100% downstream support of the filter element eliminates filter rupture, contaminant bypass and unloading Allows operation to higher differential pressures before filter change out superior flow characteristics maximizes utilization of filter surface area and maintains low operating pressure drop reduces flow per unit area (flux) for improved effluent quality greater media surface area achieves up to four times the service life as compared to conventional filter bags Improves the retention efficiency of the bag filter Greater contaminant holding capacity media layers of different porosities are combined to form a graded porosity structure each nominally rated filter medium has been optimized to achieve the longest service life advanced thermal sealing processes are used to weld the side seams to form the bag and secure the sealing ring. Thermal singe treatment of the exterior surface prevents material fibers from migrating into the clean filtered process media. Each grade of the 3M DF series filter element is manufactured from high performance fibers that are selected, based on extensive media performance testing. No adhesives, binders or silicone are used in the manufacturing processes. Applications include Industrial waters lubricants chemicals petrochemicals food wine filtration beer micro filtration process water pharmaceuticals electronics purification water treatment.
