Sandvik Coromant 5723541 T-Max Turning Shank Tool, ANSI Code: CCLNL 2525M 12-4, CCLNR/L Tool Holder, CNGN 12 07 08 Insert, Left Hand Cutting, 0.9842 in H x 0.9842 in W Rectangle Shank, -5 deg Lead Angle, -6 deg Rake, 5.9055 in OAL
Product Line: Sandvik Coromant
MFG #: 5723541
Your Price
Sandvik Coromant 5723541 T-Max Turning Shank Tool, ANSI Code: CCLNL 2525M 12-4, CCLNR/L Tool Holder, CNGN 12 07 08 Insert, Left Hand Cutting, 0.9842 in H x 0.9842 in W Rectangle Shank, -5 deg Lead Angle, -6 deg Rake, 5.9055 in OAL
Description
Sandvik Coromant Turning Shank Tool, Series: T-Max, CCLNR/L Tool Holder, 5.9055 in Overall Length, Rectangle Shank, 0.9842 in H x 0.9842 in W Shank, Insert Compatibility: CNGN 12 07 08, 43102 Insert Seat, Left Hand Cutting Direction, -5 deg Lead Angle, ANSI Code: CCLNL 2525M 12-4, ISO Code: CCLNL 2525M 12-4, -6 deg Rake, Steel
Product Number: 826223541
Manufacturer: Sandvik Coromant
Prasdsadice:
MFG #: 5723541
Manufacturer: Sandvik Coromant
Specifications
ANSI Code: CCLNL 2525M 12-4
Country of Origin: SE
Cutting Direction: Left Hand
Insert Compatibility: CNGN 12 07 08
Insert Seat Size: 43102
ISO Code: CCLNL 2525M 12-4
Lead Angle: -5 deg
Manufacturer Name: Sandvik Coromant
Material: Steel
Overall Length: 5.9055 in
Rake: -6 deg
Series: T-Max
Shank Size: 0.9842 in H x 0.9842 in W
Shank Type: Rectangle
Tool Holder Style: CCLNR/L
Item Features
- 0 deg body machine side
- 20 life cycle state
- 0 deg body workpiece side
- Without coolant entry
- Floating wedge, RC flat top
- No coolant exit
- 95 deg cutting edge
- -6 deg inclination
- 32 mm maximum overhang
- 0 deg ramping
- C-80 deg diamond insert shape
- 3 Nm torque
- 25 mm H functional
- 32 mm W functional
- 150 mm L functional
