Pramet 6751567 Turning Insert, ANSI Code: TPU 323 6640, TPUN Insert, Material Grade: K, M, P, S, 323 Insert, Triangular Shape, 16 Seat, Positive Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide
Product Line: Pramet
MFG #: 6751567
Your Price
Pramet 6751567 Turning Insert, ANSI Code: TPU 323 6640, TPUN Insert, Material Grade: K, M, P, S, 323 Insert, Triangular Shape, 16 Seat, Positive Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide
Description
Pramet Turning Insert, TPUN Insert, 323 Insert, Triangular, 4.8 mm Maximum Depth of Cut, 9.525 mm Inscribed Circle, 1/8 in Thickness, 16.5 mm Length, 16 Seat, Positive Rake, 1.2 mm Corner Radius, Manufacturers Grade: 6640, ANSI Code: TPU 323 6640, ISO Code: TPUN 160312 6640, 60 deg Included Angle, 11 deg Relief Angle, Carbide, CVD Coated, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys
Product Number: 816051567
Manufacturer: Pramet
Prasdsadice:
MFG #: 6751567
Manufacturer: Dormer Pramet
UPC: 3603602869333
Specifications
ANSI Code: TPU 323 6640
Corner Radius: 1.2 mm
Country of Origin: CZ
Finish: CVD Coated
For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys
Included Angle: 60 deg
Inscribed Circle: 9.525 mm
Insert Size: 323
Insert Style: TPUN
ISO Code: TPUN 160312 6640
Length: 16.5 mm
Manufacturer Name: Dormer Pramet
Manufacturers Grade: 6640
Material: Carbide
Material Grade: K, M, P, S
Maximum Depth of Cut: 4.8 mm
Rake: Positive
Relief Angle: 11 deg
Seat Size: 16
Shape: Triangular
Thickness: 1/8 in
