GARR 57820 1700K Double Margin Drill, 187 mm Drill - Metric, 7.3622 in Drill - Decimal Inch, 6xD D Cutting, 2 Flutes

Garr Tool Company

GARR 57820 1700K Double Margin Drill, 187 mm Drill - Metric, 7.3622 in Drill - Decimal Inch, 6xD D Cutting, 2 Flutes

FREE SHIPPING

Pricing Notice

Due to evolving trade policies, product prices may be subject to change. For details, please refer to our Terms of Sale. We remain committed to offering competitive pricing and exceptional service.

Terms of Sale

Have a Question About a Product?

Our team is here to answer all your questions and provide the detailed information and support you need to make product decisions.

Contact Us

Garr Tool Company

GARR 57820 1700K Double Margin Drill, 187 mm Drill - Metric, 7.3622 in Drill - Decimal Inch, 6xD D Cutting, 2 Flutes

FREE SHIPPING

ManufacturerGARR

Part #249057820

MFG #57820

GARR Double Margin Drill, Series: 1700K, 187 mm Drill - Metric, 7.3622 in Drill - Decimal Inch, 187 mm Overall Length, 6xD Cutting Depth, 2 Flutes, G-Style/Straight Flute, 137 mm Flute Length, 15 mm Shank, 135 deg Point, 4-Facet Point, Right Hand Cutting Direction, Submicron Grain Solid Carbide Cutting Edge, Submicron Grain Solid Carbide, Applicable Materials: Aircraft Alloys, Cast Aluminum and High Silicon Content Materials

$188.14

/ EA

QTY

Knowledgeable Product TeamBenefit from our experienced team, ready to assist you with expert product knowledge and ensure a seamless shopping experience.

Manufacturer Name: Garr Tool Company

Applicable Materials: Aircraft Alloys, Cast Aluminum and High Silicon Content Materials

Country of Origin: US

Cutting Depth: 6XD

Cutting Direction: Right Hand

Cutting Edge Material: Submicron Grain Solid Carbide

Drill Size - Decimal Inch: 7.3622 in

Drill Size - Metric: 187 mm

Flute Length: 137 mm

Flute Type: G-Style/Straight

Manufacturer Name: Garr Tool Company

Material: Submicron Grain Solid Carbide

Number of Flutes: 2

Overall Length: 187 mm

Point Angle: 135 deg

Point Type: 4-Facet

Series: 1700K

Shank Size: 15 mm

Coolant fed for accelerated feed rates and chip clearance
Strong core geometry with double margins for chip breakage and clearance
Live tooling recommended on lathe processes

GARR Double Margin Drill, Series: 1700K, 187 mm Drill - Metric, 7.3622 in Drill - Decimal Inch, 187 mm Overall Length, 6xD Cutting Depth, 2 Flutes, G-Style/Straight Flute, 137 mm Flute Length, 15 mm Shank, 135 deg Point, 4-Facet Point, Right Hand Cutting Direction, Submicron Grain Solid Carbide Cutting Edge, Submicron Grain Solid Carbide, Applicable Materials: Aircraft Alloys, Cast Aluminum and High Silicon Content Materials

Specification Sheet

Catalog

Manufacturer Name: Garr Tool Company

Applicable Materials: Aircraft Alloys, Cast Aluminum and High Silicon Content Materials

Country of Origin: US

Cutting Depth: 6XD

Cutting Direction: Right Hand

Cutting Edge Material: Submicron Grain Solid Carbide

Drill Size - Decimal Inch: 7.3622 in

Drill Size - Metric: 187 mm

Flute Length: 137 mm

Flute Type: G-Style/Straight

Manufacturer Name: Garr Tool Company

Material: Submicron Grain Solid Carbide

Number of Flutes: 2

Overall Length: 187 mm

Point Angle: 135 deg

Point Type: 4-Facet

Series: 1700K

Shank Size: 15 mm

Coolant fed for accelerated feed rates and chip clearance
Strong core geometry with double margins for chip breakage and clearance
Live tooling recommended on lathe processes

GARR Double Margin Drill, Series: 1700K, 187 mm Drill - Metric, 7.3622 in Drill - Decimal Inch, 187 mm Overall Length, 6xD Cutting Depth, 2 Flutes, G-Style/Straight Flute, 137 mm Flute Length, 15 mm Shank, 135 deg Point, 4-Facet Point, Right Hand Cutting Direction, Submicron Grain Solid Carbide Cutting Edge, Submicron Grain Solid Carbide, Applicable Materials: Aircraft Alloys, Cast Aluminum and High Silicon Content Materials

Specification Sheet

Catalog
